| Accuracy: |
Amplitude: ±0.5% rdg ±0.2% f.s., Full scale is the 3196 range value
Phase: ±1° or less (at 90 A or less), ±1.3° or less (at 90 A to 100 A) |
| Frequency Characteristics: |
66 Hz to 5 kHz (±1% or less from accuracy) |
| Max. Allowable Input: |
Continuous 130 A rms (45 to 66 Hz) |
| Max Circuit Voltage: |
300 V AC rms (insulated wire) |
| Dimensions: |
46mm (W) x 135mm (H) x 21mm (D)
1.81in (W) x 5.31in (H) x 0.83in (D) |
