| DC volts |
50.000 mV, 500.00 mV, 5.0000 V, 50.000 V, 500.00 V, 1000.0V @ 0.025% accuracy |
| AC volts |
50.000 mV, 500.00 mV, 5.0000 V, 50.000 V, 500.00 V, 1000.0V @ 0.4% accuracy (true-rms) |
| DC current |
500.00 ?A, 5000.0 ?A, 50.000 mA, 400.00 mA, 5.0000 A, 10.000 A @ 0.15 % accuracy |
| AC current |
500.00 ?A, 5000.0 ?A, 50.000 mA, 400.00 mA, 5.0000 A, 10.000 A @ 0.7% accuracy (true-rms) |
| Temperature (excluding probe) |
-200.0 ?C to 1350.0 ?C (-328.0 ?F to 2462.0 ?F) @ 1.0 % accuracy |
| Resistance |
50.000 W (289 only), 500.00 W, 5.0000 kW, 50.000 kW, 500.00 kW, 5.0000 MW, 50.00 MW, 500.0 MW @ 0.05 % accuracy |
| Capacitance |
1.000 nF,10.00 nF 100.0 nF, 1.000 ?F, 10.00 ?F, 100.0 ?F, 1000 ?F, 10.00 mF, 100.00 mF @ 1.0 % accuracy |
| Frequency |
99.999 Hz, 999.99 Hz, 9.9999 kHz, 99.999 kHz, 999.99 kHz @ 0.005 % + 1 accuracy |
