| Measurement Parameters: |
Z|, phase angle, C, L, D, Q, R |
| Measurement Method: |
Source: constant voltage 50 mV to 1 V rms (AC)
Sense: voltage, AC |
| Measurement Ranges: |
Z|, R: 10 m-Ohm to 200.00 M-Ohm (depending on condition), phase angle: -90.00 to +90.00 °, C: 0.940 pF to 999.99 mF, L: 1.600 µH to 200.00 kH, D: 0.0001 to 1.9900, Q: 0.85 to 999.99 |
| Basic Accuracy: |
|Z|: ±0.08 % rdg. , phase angle: ±0.05 ° |
| Measurement Times: |
Fast: 5 msec. to Slow: 300 msec. (at 1 kHz)
Fast: 13 msec. to Slow: 400 msec. (at 120 Hz) |
| Comparator Functions: |
Setting: Upper and lower limit, absolute value
Output: 3 levels (Hi, In, Lo), Open-collector, Isolated |
| External Printer: |
9442 (use with the 9443-02 or -03/9444) |
| Power Supply: |
100 to 240 V AC (Selectable type) 50/60 Hz |
| Dimensions: |
210 mm(8.27 in)W × 100 mm(3.94 in)H × 168 mm(6.61 in)D |
