| FEATURE |
AM-560 |
Best Accuracy |
| True-rms |
χ |
|
| AC Voltage |
6.000 V, 60.00 V, 600.0 V, 1000 V |
+/- (1.0 % rdg + 3 LSD)
@ 45 Hz to 400 Hz, 0 V to 600 V |
| DC Voltage |
600.0 mV, 6.000 V, 60.00 V,
600.0 V, 1000 V |
+/- (0.5% rdg + 2 LSD) @ 6 V to 600 V ranges |
| AC Current |
600.0 µA, 6000 µA,
60.00 mA, 500.0 mA,
10.00 A |
+/- (2.0% rdg + 5 LSD)
@ 45 Hz to 400 Hz |
| DC Current |
600.0 µA, 6000 µA,
60.00 mA, 500.0 mA,
10.00 A |
+/- (1.5% rdg + 3 LSD) |
| Frequency |
60.00 Hz, 600.0 Hz,
6.000 kHz, 60.00 kHz, 600.0 kHz,
6.000 MHz, 60.00 MHz |
+/- (0.1% rdg + 3 LSD) |
| Resistance |
600.0 Ω,
6.000 kΩ, 60.00 kΩ, 600.0 kΩ
6.000 MΩ 60.00 MΩ |
+/- (1.0% rdg + 2 LSD)
@ 6 kO to 600 kΩ ranges |
| Capacitance |
60.00 nF, 600.0 nF,
6.000 µF, 60.00 µF, 600.0 µF, 6000 µF,
60.00 mF |
+/- (3.0% rdg + 5 LSD)
@ 600 nF to 60 µF ranges |
| Temperature |
-40 °F to 1832 °F
-40 °C to 1000 °C |
+/- (1.0% rdg + 12) @ >104 °F to 752 °F
+/- (1.0% rdg + 8) @ >40 °C to 400 °C |
| Number of temperature inputs |
Dual Thermocouple |
|
| Duty cycle |
10.00% to 90.00% |
+/- (1.2% rdg + 30 LSD) @ 5 Hz to 2 kHz |
