Rigol Rigol DS1074z vs DS2072-Rule Based Do No Use




Comparison of the Rigol DS1074z and DS2072A Digital Oscilloscopes:

Both the Rigol DS2072a and DS2202 from the DS2000 oscilloscope series come with Rigol's innovative technology, industry leading specifications, powerful trigger functions and analysis capabilities.
Rigol DS2072a comes with Rigol's "UltraVision" technology, full bandwidth, lower overshoot, and many other features.

Rigol DS1074z comes with Rigol's "UltraVision" technology, 4 channels, a variety of math functions, and many other features.


Rigol DS1074ZDS2072A
The key differences are listed here:


 Feature / Model DS2072a DS1074z
Bandwidth 70 MHz 70 MHz
Memory 14 MP 12 MP
Rise Time 5 ns 5 ns
Data Logging Yes Yes
UltraVision Technology Yes Yes
Sampling Rate 1 GS/s 2 GS/s
For the Full Details of the differences please see below:
(click the ? for explanations of specification terms)

ModelRigol DS2072Rigol DS1074Z
Product70 MHz Digital Oscilloscope with 2 channels70 MHz Digital Oscilloscope with 4 channels plus 12 Mpt memory and 1 GSa/sec...
Rating(20)(55)
Price
In Stock

Oscilloscopes/Digital Oscilloscopes

Bandwidth70 MHz70 MHz
Channels24
Sampling Rate2 GS/S1 GS/S
Memory14 MB (14336 kB)12 MP [megapoints] (12288 kB)
Rise Time5 ns5 ns
Screen Size8 IN7 IN

Test Equipment General Attributes

Unique Features 500 uV range available
56 M memory available		Optional Serial Bus Triggering and Decoding functions(RS232,I2C,SPI)

Factory calibrated is included
Warranty3 YEARS3 YEARS
Safety ApprovalCE
Interfaces I/O LAN / Ethernet, USB, VGA or SVGA Out LAN / Ethernet, LXI, USB Host, USB
StorageCompact FlashUSB Flash Drive
