| Application | Building Inspection |
| Measurement Range | -4° to 257°F (-20° to 125°C) |
| Field of View | 20° x 15° |
| Focus | Manual Focus with 2X Digital Zoom |
| Minimum Focus | 11.81" (30cm) |
| Spectral Response | 8 µm to 14 µm |
| Thermal Sensitivity | NETD ≤ 50 mK (0.05°C) @ 23°C ambient and 30°C Scene Temperature |
| Frame Rate | 9 Hz Frame Rate |
| Detector | Advanced high resolution 160 x 120 detector with 19,200 pixels |
| Image Storage | Over 1,000 images on supplied SD Card (or MMC)
Multiple image storage and retrieval at full digital resolution.
Image browser with full image adjustment. |
| Accuracy | The greater of ± 2°C or ± 2% of reading in °C |
| Display | 3-1/2" Color LCD and LED Backlight with high resolution images, show images clearly and precisely. |
| Color Palettes | 4 Color Palettes: Rainbow, Ironbow, High Contrast, and Grayscale |
| Laser Pointer | Trigger activated Class II Laser to highlight the center of the imaged area |
| Radiometry | Dual moveable temperature measurement cursors, with auto seek on the hottest and coldest points. Delta temperature measurement. |
| Emissivity Correction | User selectable 0.2 to 1.0 in steps of 0.01 with reflected ambient temperature compensation. |
| Ambient Operating Range | 5° to 113°F (-15° to +50°C) |
| Storage Range | -4° to 158°F (-20° to +70°C) |
| Readout | °C, °F or K |
| IP Rating | IP42 |
| MIL SPECS | MIL-PRF-288-F Class 2. Vibration: Section 4.5.5.3.1.
Shock: Section 4.5.5.4.1. Drop: Section 4.5.5.4.2 |
| Humidity | 10% to 90% non-condensing |
| Power | Field rechargeable, replaceable, high capacity, Lithium-ion batteries with up to 6 hrs continuous operation, AC Adapter included. Battery charge indicator. |
| Settings and Controls | ON/OFF soft power control; user selectable, and auto adjustable span and level control. |
| Interfaces | USB Type B |
| Housing | Impact Resistant Plastic with Protective Rubber Boot and Wrist Strap |
| Dimensions | 9.05 x 4.72 x 4.33 inches (230mm x 120mm x 110mm) |
| Weight (with Battery) | approx. 1.65 lbs (0.75kg) |
| Mounting | Hand Held & Tripod Mounting |
| Included Accessories | Easy Report & Report Writer Software, Rubber Boot, Carrying Case, Wrist Strap, Rechargeable Battery, AC Adapter, Car Charger, User Manual and Image Analysis Software CD, USB Cable, SD Card, and SD Card Reader. |
| Optional Accessories | Desktop Charger, Car Charger, Magnifying Eye Piece/Sun Shade, Rubber Boot, and additional Rechargeable Battery.
Also, Portable Calibration Black Body |
