Testo 521-2 - Differential Pressure Instrument 0 to 100 hPa (±0.1% of f.v.) (Part Number 0560 5211)

Name: Testo 521-2 - Differential Pressure Instrument 0 to 100 hPa (±0.1% of f.v.) (Part Number 0560 5211)
Brand: Testo
SKU: Testo521-2
Price: 1474.75 USD
Availability: InStock

0 reviews | Catalog: 0560 5211 | UPC: 4029547015540 | Model: Testo 521-2

Compare

testo 521-2 (0 to 100hPa/ +/-40 inch WC, 0.1% acc.)

Temperature-compensated differential pressure sensor in instrument
Additional 2 probe inputs for the connection of further probes for the measurement of pressure and temperature
Direct calculation of flow velocity and volume flow
Direct zeroing of display value from pressure probes
Display of Hold, max. and min. values
Easy data storage by measurement site as well as analysis, archiving and documentation via optional PC software
Point and timed mean value calculation
PROBES SOLD SEPARATELY – click here for probe list

View Product Details

List Price: $1,735.00

In Stock:

View Payment Options

Recommended for you

Accessories

Choose a Category

for the Testo 521-2

Testo 0515 0025 NiMH-battery IEC 6F22 / 9V 250mAh

Catalog: 0515 0025

(0)

In Stock!

Add to Cart

Testo 0554 1143 AC power supply / charger, 110V for 475 & 535

Catalog: 0554 1143

(0)

In Stock!

Add to Cart

Testo 0409 0178 RS 232 data transfer cable, 5.9 ft / 1.8 m

Catalog: 0409 0178

(0)

In Stock!

Add to Cart

Testo 0409 0202 Connector cable high pressure probes

Catalog: 0409 0202

(0)

In Stock!

Add to Cart

Testo 0554 0440 Silicone hose (16' long) for pressure measument

Catalog: 0554 0440

(0)

In Stock!

Add to Cart

Testo 0554 0549 Universal Fast Infrared Printer is for use with the Testo 320...

Catalog: 0554 0549

(0)

In Stock!

Add to Cart

Testo 0635 2045 19 inch pitot tube (need hose 0554 0440)

Catalog: 0635 2045

(0)

In Stock!

Add to Cart

Testo 0635 2140 Straight pitot tube 20 inch NiCr-Ni 1112 Degrees F w/ T/C, w/ hose

Catalog: 0635 2140

(0)

In Stock!

Add to Cart

Testo 0635 2145 L"-type pitot tube 13 inch SS 1112 Degrees F no T/C (need hose 0554 0440)

Catalog: 0635 2145

(0)

In Stock!

Add to Cart

Testo 0635 2240 Straight pitot tube 39 inch NiCr-Ni 1112 Degrees F w/ T/C, w/hose

Catalog: 0635 2240

(0)

In Stock!

Add to Cart

Testo 0635 2345 L"-type pitot tube 40 inch stainless steel 1112 Degrees F max (need...

Catalog: 0635 2345

(0)

In Stock!

Add to Cart

Testo 0638 1741 Pressure probe 10 bar (150 psi)

Catalog: 0638 1741

(0)

In Stock!

Add to Cart

Testo 0554 0568 Thermal printer paper - 6 rolls (10 year legibility)

Catalog: 0554 0568

(0)

In Stock!

Add to Cart

Testo 521-2 - Differential Pressure Instrument 0 to 100 hPa (±0.1% of f.v.) (Part Number 0560 5211)

Integrated differential pressure sensor with an accuracy of 0.1% of f.v.
Calculation of flow velocity and volume flow via pitot tube (optional)
Multi-point and timed mean calculation
2 probe inputs for additional pressure and temperature probe
PROBES SOLD SEPARATELY - click here for probe list

The testo 521 series are highly accurate differential pressure measuring instruments with an internal sensor. The testo 521-1 and testo 521-2 both have a measuring range from 0 to 100 hPa, however they are available in two accuracy classes:

testo 521-1: accuracy 0.2 % of final value
testo 521-2: accuracy 0.1 % of final value

The 521-1 and 521-2 are optimally suited to checks on extraction systems and ventilators, as well as the monitoring of pressure drop at filters. In combination with a Pitot tube, the internal sensor measures flow velocities from 5 to 100 m/s. The instrument additionally has two probe inputs for the connection of further probes for the measurement of pressure and temperature. A large selection of probes is available for this purpose.

The testo 521-3 has a measuring range of 0 to 2.5 hPa and records even the smallest pressure differences without difficulty. Its high accuracy and a resolution of 0.1 Pa make it ideal for differential pressure measurements in cleanrooms. In combination with the Pitot tube, the internal sensor measures flow velocities from 1 to 20 m/s. The testo 521-3 is also equipped with two probe inputs for the connection of further probes for the measurement of pressure and temperature.

Advantages testo 521

Built-in differential pressure probe
2 user defined probe sockets for pressure and temperature
Wide selection of probes
Documentation on site
Easy data management via PC
2 line display with text menu guide
Mains socket/fast battery recharging
Fast-action coupling connections M8x0.5

Specifications
Temperature - NTC
Measuring range	-40° to 302 °F / -40 to +150 °C
Accuracy	±0.4 °F (14° to 122 °F)* / ±0.2 °C (-10 to +50 °C)* ±0.7 °F (Remaining Range)* / ±0.4 °C (Remaining Range)*
Resolution	0.1 °F / 0.1 °C
*Accuracy information applies only to instrument without probes connected
Temperature - Type K TC
Measuring range	-328° to 2498 °F / -200 to +1370 °C
Accuracy	±0.7 °F (-148° to 392 °F)* / ±0.4 °C (-100 to +200 °C)* ±2 °F Remaining Range* / ±1 °C Remaining Range*
Resolution	0.1 °F / 0.1 °C
*Accuracy information applies only to instrument without probes connected
Differential pressure (internal sensor) - Piezoresistive
Measuring range	0 to 40 InH₂O / 0 to 100 hPa
Accuracy	±0.1 % of full-scale value
Resolution	0.01 InH₂O / 0.01 hPa
Static pressure	400 InH₂O (abs) / 1000 hPa
Overload	120 InH₂O / 300 hPa
Zeroing	to 1.0 InH₂O / to 2.5 hPa
Differential pressure (external probe) - Piezoresistive
Measuring range	0 to 800 InH₂O / 0 to 2000 hPa
Accuracy	±0.1 % of mv*
Resolution	0.1 InH₂O (0638 1347) 0.01 InH₂O (0638 1547) / 0.01 hPa (0638 1547) 0.001 InH₂O (0638 1447) / 0.001 hPa (0638 1447) 0.1 InH₂O (0638 1847 / 0638 1647) / 0.1 hPa (0638 1847 / 0638 1647)
*Accuracy information applies only to instrument without probes connected
Differential pressure (external probe) - Ceramic
Measuring range	-15 to 5802 psi / -1 to 400 bar
Accuracy	±0.2 % of full-scale value*
Resolution	0.14 psi / 0.01 bar
*Accuracy information applies only to instrument without probes connected
General technical data
Dimensions	9 x 3 x 2 in. / 219 x 68 x 50 mm
Operating temperature	32° to 122 °F / 0 to +50 °C
Housing	ABS
Channels	2 external; 1 internal
Measuring rate	0.04 sec
Connection	Hose: inner Ø 4 mm outer Ø 6 mm
Battery type	9 V (6LR61)
Battery life	Continuous operation w/ internal pressure sensor: 30 h; With rech. battery: 10 h; With carbon battery: 18 h
Display type	LCD
Display function	7 segment display and point matrix
Display update	2x per second, in fast measurement 4x per second
Power supply	Battery/Rechargeable battery,Mains unit 12 V
Interface	RS232
Memory	100 kB; 25,000 measuring values
Storage temperature	-4° to 158 °F / -20 to +70 °C
Weight	11 oz. / 300 g

Tech Specs

Test Equipment General Attributes
Product Height	4.00 IN
Product Length	12.00 IN
Product Width	6.00 IN
HTS/Schedule B Number	90262020000
ECCN Number	EAR99
Country of Origin	Germany
Shipping Height	4.00 IN
Shipping Length	12.00 IN
Shipping Width	6.00 IN

Start typing your question...

Answers (1) - Asked by Anonymous

I have this question too (0)

These devices are similar, however, they cover different pressure ranges and accuracy levels. • 521-1 ? 0 to 100 hPa ? (±0.2% of f.v.) • 521-2 ? 0 to 100 hPa ? (±0.1% of f.v.) • 521-3 ? 0 to 2.5 hPa ? ±0.5 Pa (0 to 20 Pa) ? ±(0.5 Pa ±0.5 % of mv) (20.1 to 250 Pa)
