Simpson 03590 Century, Round, Rectangular and Wide-Vue Style Elapsed Time Meter

Name: Simpson 03590 Century, Round, Rectangular and Wide-Vue Style Elapsed Time Meter
Brand: Simpson
SKU: Simpson03590
Price: 166.86 USD
Availability: InStock

0 reviews | Catalog: 03590 | Model: Simpson 03590

Compare

57ET--- 60HZ 120VAC3.5 UL RECT

Records the “On” Time of Electrical Equipment
AC & DC Operating Voltage Units
Phenolic Cases With Glass Windows
Six Attractive Case Styles
Two Popular Sizes: 1-1/2", 3-1/2"

View Product Details

List Price: $191.53

Your Price: $166.86

Sign-in for EDU Pricing!

In Stock:

View Payment Options

Request Quote

Items in This Series


Product	Simpson 03590 57ET--- 60HZ 120VAC3.5 UL RECT	Simpson 03610 57ET--- 60HZ 240VAC3.5 UL RECT
Price
In Stock
Style (Panel Meter)	Rectangular/Square	Rectangular/Square
Number of Inputs (Panel Meters)	Single	Single
Mounting (Panel Meter)	Panel Mount	Panel Mount
Compare	Add to compare	Add to compare

Recommended for you

Simpson’s series of elapsed time meters features a six-digit readout with no reset capability, making them virtually tamper proof. Each true-time elapsed time meter is ruggedly constructed and records the “on” time of electrical equipment. They are widely used in factory environments where there is a need to accumulate running time and monitor life and performance records on AC and DC powered equipment. All hour meters are connected in parallel with the equipment being monitored. The synchronous motor provides accurate hour indication. Model 109ET has a 10-80 V DC input as a standard feature. An optional plug-in AC converter module can also be ordered with the model 109 ET. Choose from Century, Wide-Vue, Rectangular or Round case styling to match other instruments.

Accuracy	Model 109ET & 112ET: <.01%/24 HRS. Models 55ET, 1357ET, 57ET, 2153:synchronous with AC power
Movement	Synchronous clock motor
Overload(1 sec)	0 times F.S.
Maximum Indication	99,999.9 Hours
Power Consumption	Models 109ET, 112ET: .5 watts
All Other Models	2.5 watts
Case	Models 55ET, 57ET, 2153ET: High density phenolic Models 109ET, 112ET, 1357ET: High density black acrylic
Operating Temperature	-4ºF to +149ºF (-20ºC to +65ºC)
Net Weight	Models 112ET, 109ET: 2.5 oz (0.07kg) Models 55ET, 57ET: 12.5 oz (0.35kg) Model 1357ET, 2153ET: 13 oz (0.37kg)

Panel Meters/Panel Meters Template
Style (Panel Meter)	Rectangular/Square
Number of Inputs (Panel Meters)	Single
Mounting (Panel Meter)	Panel Mount
Input (Panel Meters)	Other Input (Panel Meters) Time
Size-Circular	2.81 IN
Size-Face Width	3 1/2 in
Process Output	No
Control / Alarm Setpoints	No
Water Proof	No
Splash Proof	No
Relay Output	No
Test Equipment General Attributes
Country of Origin	United States
