| DC VOLTAGE |
| Ranges |
250mV, 1V, 2.5V, 10V, 50V, 250V, 500V,1000V |
| Accuracy |
1.25% of full scale @ 77°F, 1.75% of full scale @ 67-87°F |
| Sensitivity |
20KΩ per volt |
| AC VOLTAGE |
| Ranges |
2.5V, 10V, 50V, 250V, 500V, 1000V |
| Accuracy |
2% of full scale @ 77°F, 3% of full scale @ 67-87°F |
| Sensitivity |
5KΩ per volt |
| DECIBEL |
| 5 Ranges |
-20 to +50dB |
| Reference |
0dB= 1mW into 600Ω |
| DC CURRENT |
| Ranges |
50μA, 1mA,10mA, 100mA, 500mA, 10A |
| Accuracy |
0.75% of full scale on 50μA @77°F, 1.25% full scale of all others @77°F, 1.25% of full scale on 50μA @ 67-87°F, 1.75% of full scale of all others @ 67-87°F |
| Voltage Drop: (Nominal) |
250mV On 50μA and 1mA, 255mV On 10mA anmd 10A, 300mV On 100 mA, 500mV On 500mA |
| RESISTANCE |
| Ranges |
Rx 1, Rx 100, Rx 10K |
| Accuracy |
1.5° of arc on Rx1, 1.0° of arc on other |
| Maximum Indication |
0-2KΩ, 0-200Ω, 0-20MΩ |
| General Specifications |
| Batteries |
1.5V AA, 9V (NEDA No. 13F,1604A) |
| Fuse |
F1 1A, 250V, type 3AG, quick acting Littelfuse® Type 312001; F2 2A, 600V Littelfuse® Type BLS or 2A 600V, Bussman® Type BBS. |
| Size |
7”(H) x 5.5”(W) 3.1”(D) (18x14x8cm) |
| Weight |
Approximately 3LBS. (1.4Kg) |
| Rated Circuit-To-Ground Voltage |
1000V AC/DC Max |
