Simpson 00110 DC Current Round Style Panel Meter

Name: Simpson 00110 DC Current Round Style Panel Meter
Brand: Simpson
SKU: Simpson00110
Price: 116.81 USD
Availability: InStock

0 reviews | Catalog: 00110 | Model: Simpson 00110

Compare

25A---- 0-75 DCA 3.5 UL RND

±2% Full Scale Accuracy
UL Recognized
Phenolic Case with Glass Windows
Calibration Not Affected By Steel Mounting
Distinctive Case Style
Two Popular Sizes: 2-1/2" & 3-1/2"

View Product Details

List Price: $137.44

Your Price: $116.81

Sign-in for EDU Pricing!

In Stock:

View Payment Options

Request Quote

Items in This Series



Product	Simpson 00110 25A---- 0-75 DCA 3.5 UL RND	Simpson 00005 25A---- 0-1 DCA 3.5 UL RND	Simpson 00040 Z 25A---- 0-3 DCA 3.5 UL RND	Simpson 00210 Z 25A---- 30-0-30DCA 3.5 UL RND	Simpson 00099 25A---- 0-50 DCA 3.5 UL RND	Simpson 00200 25A---- 15-0-15DCA 3.5 UL RND	Simpson 00070 25A---- 0-15 DCA 3.5 UL RND	Simpson 00090 25A---- 0-30 DCA 3.5 UL RND	Simpson 00160 25A---- 0-300 DCA 3.5 UL RND	Simpson 00220 25A---- 50-0-50DCA 3.5 UL RND	Simpson 00060 25A---- 0-10 DCA 3.5 UL RND	Simpson 00151 25A---- 0-250 DCA 3.5 UL RND	Simpson 00140 Z 25A---- 0-200 DCA 3.5 UL RND	Simpson 00030 25A---- 0-2 DCA 3.5 UL RND	Simpson 00130 25A---- 0-150 DCA 3.5 UL RND	Simpson 00080 Z 25A---- 0-25 DCA 3.5 UL RND	Simpson 00177 25A---- 0-750 DCA 3.5 UL RND	Simpson 00170 25A---- 0-500 DCA 3.5 UL RND	Simpson 00120 25A---- 0-100 DCA 3.5 UL RND	Simpson 00050 25A---- 0-5 DCA 3.5 UL RND	Simpson 00188 25A---- 0-1000 DCA 3.5 UL RND
Price
In Stock
Type (Panel Meter )	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog
Style (Panel Meter)	Circular	Circular	Circular	Circular	Circular	Circular	Circular	Circular	Circular	Circular	Circular	Circular	Circular	Circular	Circular	Circular	Circular	Circular	Circular	Circular	Circular
Number of Inputs (Panel Meters)	Single	Single	Single	Single	Single	Single	Single	Single	Single	Single	Single	Single	Single	Single	Single	Single	Single	Single	Single	Single	Single
Compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare

Recommended for you

For industrial or commercial applications, the Round style panel meter offers maximum reliability and ±2% full scale (F.S.) accuracy. With a black phenolic case and glass window for optimum viewing, the Round style meter is a popular replacement. All DC units have pivot and jewel suspensions that are spring-loaded for shock protection. The selfshielded meter movement prevents magnetic interaction between the meter and a steel panel. Two popular sizes of 2-1/2" and 3-1/2" are available to measure various voltage ranges up to 1000 amps. DC current meters are self contained for ranges up to and including 50 amperes. Higher range DC current meters require external shunts.

Accuracy	±2% F.S.
Movement	Annular, self-shielding
Suspension	Models 25, 125: Pivot and Jewel
Tracking	±3%
Shielding	Calibration is unaffected by magnetic panel mounting.
Response Time	1.5 seconds maximum
Overload (1 sec.)	10 times full scale rating
Overload (Continuous)	1.5 times full scale rating
Repeatability	Models 25, 125: 2%; Models 25T, 125T: 0.5%
Dial	Sharp clear scale. Each dial arc is calibrated to track the specific type of movement used.
Resistance	±15%
Operating Temperature	-4ºF to +149ºF (-20ºC to +65ºC)
Repeatability	2%
Case	High density black phenolic.
Pointer	SpadePointer, with black matte finish.
Scale Length	Model 25: 2.5" (63.5 mm) Model 125: 1.8" (45.7 mm)
Net Weight	Model 25: 8 ozs (0.23 kg) Model 125: 7 ozs (0.20 kg)

Panel Meters/Panel Meters Template
Type (Panel Meter )	Analog
Style (Panel Meter)	Circular
Number of Inputs (Panel Meters)	Single
Mounting (Panel Meter)	Panel Mount
Input (Panel Meters)	Current
Size-Circular	2.82 IN
Size-Face Width	3 1/2 in
Process Output	No
Control / Alarm Setpoints	No
Water Proof	No
Splash Proof	No
Relay Output	No
Test Equipment General Attributes
Country of Origin	United States
