SBS 50-469-BB Battery Testers and Monitors

Name: SBS 50-469-BB Battery Testers and Monitors
Brand: Storage Battery Systems
SKU: SBS50-469-BB
Price: 5250.00 USD
Availability: InStock

0 reviews | Model: Storage Battery Systems 50-469-BB

Compare

Portable Battery Monitor/Ground Fault Locator

DC Bus 90 - 180 VDC (125 Nominal)
Battery bus to ground voltage
Total ground fault voltage
Battery bus voltage
Measurements made with non-contacting interface sensor; no contact with live bus measurement - no potential hazardous to user

View Product Details

List Price: $5,600.00

In Stock:

View Payment Options

Recommended for you

General Specifications
Battery Input:	90 to 180 VDC, 3VA - For 125V battery
Ground Resistors:	30K ±1% from each bus to ground
Voltage Indication:	0 to ±199.9 VDC in 0.6” bright red LED digit and decimal point accuracy is ±0.2 VDC
Ranges:	+Bus to Ground (+GND) -Bus to Ground (- to GND) Ground Fault Voltage (Fault) Battery Voltage (BAT)
Scanning:	Each range is automatically scanned and read every three seconds.
Alarms:	The “+/- Fault” relay energizes and latches when the + fault voltage exceeds the +/- set value for the time setting. The “alarm” LED lights. Set range is 13.0 to 100.0V “Hi Battery” and “Low Battery” relays energize and latch when the battery voltage exceeds the “Hi” or "Low" set value for the time setting. (“Hi” set range is 125.0 to 150.0V, and the "Low" set range is 100.0 to 125.0V)
Time Delay:	Can be set from 5 to 60 seconds
Reset:	Panel push button or remote contact closure will reset an alarm provided the cause is removed
Contact Rating:	2A at 120 VAC or 28 VDC
Limit Setting:	Limits and time delay are set by removing the front bezel (4 screws). This can safely be done with power on.
Output Options:	0 to 1mADC (isolated) into 0 to 10K load for 90 to 180 VDC input. Accuracy is ±0.1% of FS. P/N is 50-469-I01-BB 4 to 20 mADC (isolated) into 0 to 500 OHM load for 90 to 180 VDC input. Accuracy is ±0.1% of FS. P/N is 50-469-I420-BB Digital: RS232/485 with DNP3.0 or Modbus, P/N is 50-469-J3.0-BB
