| CAN triggering and decoding |
| Bus configuration |
signal type |
CAN_H, CAN_L |
| sources |
channel 1, channel 2, logic channels from D7 to D0 |
| bit rate |
10/20/33.3/50/83.3/100/125/250/500/ 1000 kbps or user-selectable in range from 100 bps to 2 Mbps |
| sampling point |
10 % to 90 % within bit period |
| label list |
associate frame identifier with symbolic ID |
| Trigger |
trigger events |
start of frame, frame type, identifier, identifier + data, error condition (any combination of CRC error, bit stuffing error, form error and ACK error) |
| identifier setup |
frame type (data, remote or both), identifier type (11 bit or 29 bit); condition =, ≠, >, <; identifier selectable from label list |
| data setup |
data pattern up to 8 byte (hex or binary); condition =, ≠, >, < |
| Decode |
displayed signals |
bus signal, logic signal or both |
| color coding of bus signal |
start of frame, identifier, DLC, data payload, CRC, ACK, end of frame, error frame, overload frame, CRC error, bit stuffing error, ACK error |
| displayed format of data |
hex, decimal, binary, ASCII |
| frame table |
decode results displayed as tabulated list, errors highlighted in red; three table positions (top, bottom, full screen); frame navigation; data export as CSV file |
| Search |
search events |
frame, error, identifier, identifier + data, identifier + error |
| frame event setup |
start of frame, end of frame, overload frame, error frame, data ID 11 bit, data ID 29 bit, remote ID 11 bit, remote ID 29 bit |
| error event setup |
any combination of CRC error, bit stuffing error, form error and ACK error |
| identifier setup |
frame type (data, remote or both), identifier type (11 bit or 29 bit); condition =, ≠, >, <; identifier selectable from label list |
| data setup |
data pattern up to 8 byte (hex or binary); condition =, ≠, >, < |
| event table |
search results displayed as tabulated list; event navigation |
| LIN triggering and decoding |
| Bus configuration |
version |
1.3, 2.x or SAE J602; mixed traffic is supported |
| bit rate |
1.2/2.4/4.8/9.6/10.417/19.2 kbps or userselectable in range from 1 kbps to 5 Mbps |
| polarity |
active high or active low |
| label list |
associate frame identifier with symbolic ID |
| Trigger |
source |
any input channel |
| trigger events |
start of frame (sync break), identifier, identifier + data, wakeup frame, error condition (any combination of checksum error, parity error and sync field error) |
| identifier setup |
range from 0d to 63d; condition =, ≠, >, <; identifier selectable from label list |
| data setup |
data pattern up to 8 byte (hex or binary); condition =, ≠, >, < |
| Decode |
displayed signals |
bus signal, logic signal or both |
| color coding of bus signal |
frame, frame identifier, parity, data payload, checksum, error condition |
| displayed format of data |
hex, decimal, binary, ASCII |
| frame table |
decode results displayed as tabulated list, errors highlighted in red; three table positions (top, bottom, full screen); frame navigation; data export as CSV file |
| Search |
search events |
frame, error, identifier, identifier + data, identifier + error |
| frame event setup |
start of frame, wake up |
| error event setup |
any combination of checksum error, parity error and sync field error |
| identifier setup |
range from 0d to 63d; condition =, ≠, >, <; identifier selectable from label list |
| data setup |
data pattern up to 8 byte (hex or binary); condition =, ≠, >, < |
| event table |
search results displayed as tabulated list; event navigation |
