PIE 520B-E Thermocouple Calibrator, single source for E type thermocouples

0 reviews | Model: PIE 520B-E

Compare

Thermocouple source calibrator- single type E. Comes with test leads and NIST cert.

Accuracy ±(0.015% of mV Setting + 0.009mV)
Calibrate in temperature for your T/C type
Adjustable temperature output in selectable 1°C or 1°F steps
Typical accuracy of ±0.35°C (0.5°) for Type K
EZ-Dial knob easily adjust output by °C or °F with 1.0° resolution
Three position EZ-Check™ switch for 0% and 100% span adjustments
Uses standard "AA" Alkaline Batteries
Superior battery life of 45 hours under typical continuous usage
Easy access to battery compartment
Lightweight and Rugged with a Solid Feel
Small and tough
Protected to 60V

View Product Details

Your Price: $725.00

Sign-in for GSA and EDU Pricing!

In Stock:

Click for Altek Calibrator Trade-In Program

Have a functional or non-functional Altek calibrator laying around? Trade it in and get 10% off a brand new PIE model.

Contact us today to learn more!
View Payment Options

Request Quote

Items in This Series



Product	PIE 520B-E Thermocouple source calibrator- single type E. Comes with test leads and NIST c ...	PIE 520B-G Thermocouple source calibrator- single type G. Comes with test leads and NIST c ...	PIE 520B-S Thermocouple source calibrator- single type S. Comes with test leads and NIST c ...	PIE 520B-J Thermocouple source calibrator- single type J. Comes with test leads and NIST c ...	PIE 520B-P Thermocouple source calibrator- single type P. Comes with test leads and NIST c ...	PIE 520B-B Thermocouple source calibrator- single type B. Comes with test leads and NIST c ...	PIE 520B-N Thermocouple source calibrator- single type N. Comes with test leads and NIST c ...	PIE 520B-U Thermocouple source calibrator- single type U. Comes with test leads and NIST c ...	PIE 520B-D Thermocouple source calibrator- single type D. Comes with test leads and NIST c ...	PIE 520B-K Thermocouple source calibrator- single type K. Comes with test leads and NIST c ...	PIE 520B-C Thermocouple source calibrator- single type C. Comes with test leads and NIST c ...	PIE 520B-R Thermocouple source calibrator- single type R. Comes with test leads and NIST c ...	PIE 520B-L Thermocouple source calibrator- single type L. Comes with test leads and NIST c ...	PIE 520B-T Thermocouple source calibrator- single type T. Comes with test leads and NIST c ...	PIE 521B 14 type T/C Source only And mV. Includes mV leads and FREE NIST Traceable Certifi ...
Price
In Stock
Type	Hand Held	Hand Held	Hand Held	Hand Held	Hand Held	Hand Held	Hand Held	Hand Held	Hand Held	Hand Held	Hand Held	Hand Held	Hand Held	Hand Held	Hand Held
Measure Inputs	No	No	No	No	No	No	No	No	No	No	No	No	No	No
Source Outputs	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare

Recommended for you

PIE 520B-E Accessories

Choose a Category

for the PIE 520B-E

PIE 020-0207 mA/V Test Leads - 1 red/1 black with Banana plugs to Alligator clips

Catalog: 020-0207

(1)

In Stock!

Add to Cart

PIE 020-0103 NiMh Charger And 4 "AA" batteries. Universal 120 to 240 V AC 50/60Hz...

Catalog: 020-0103

(0)

In Stock!

Add to Cart

PIE 020-0209 Black Rubber Boot for Evolution Milliamp calibrators

Catalog: 020-0209

(0)

In Stock!

Add to Cart

PIE 020-0202 T/C - J, T, E, K Mini plug lead kit

Catalog: 020-0202

(0)

In Stock!

Add to Cart

PIE 020-0203 T/C - B, R/S, N Mini plug lead kit

Catalog: 020-0203

(0)

In Stock!

Add to Cart

PIE RP-WAR-A 3 Year Full Coverage Repair/Replacement Warranty all models except 820,...

Catalog: RP-WAR-A

(0)

In Stock!

Add to Cart

PIE 520B Thermocouple Calibrator

Accuracy ±(0.015% of mV Setting + 0.009mV)
Calibrate in temperature for your T/C type
Adjustable temperature output in selectable 1°C or 1°F steps

The PIECAL 520B Thermocouple Simulator simulates a dedicated standard thermocouple curve over the entire industrial temperature range. The PIECAL 520B provides precise temperatures for inputs to all types of instruments such as transmitters, recorders, controllers, alarms, data acquisition, and computer systems. PIECAL 520B is cold-junction compensated for changes in ambient temperature. The PIECAL 520B offers the highest performance and functions in its class by exceeding the accuracy and functions of many higher priced thermocouple calibrators.

PIE 520B General Specifications (Unless otherwise indicated all specifications are rated from a nominal 23 °C, 70 % RH for 1 year from calibration)
Accuracy	±(0.015% of Reading + 0.009 mV)
Temperature Drift	± 0.45°F (±0.25 °C)
Millivolt Range	-13.000 to 80.000 mV
Operating Temperature Range	-25 to 60 °C (-10 to 140 °F)
Temperature Drift	≤ 50 ppm of range (includes mV and Cold Junction)
Relative Humidity Range	10 % ≤RH ≤90 % (0 to 35 °C), Non-condensing 10 % ≤RH≤ 70 % (35 to 60 °C), Non-condensing
Size	With Boot 4.96 x 2.73 x 1.79 inches, 126 x 69 x 45 mm (L x W x H) 5.67 x 3.06 x 2.05 inches, 144 x 78 x 52 mm (L x W x H)
Weight	With Boot 8.4 ounces, 0.24 kg (including batteries) 11 ounces, 0.32 kg (including batteries)
Batteries	Four “AA” Alkaline 1.5V (LR6)
Battery Life	50 Hours
Optional NiMh Rechargeable battery kit	120 VAC for North America Only; charger, four NiMh batteries, AC & DC cords [Part # 020-0103]
Low Battery	Low battery indication with nominal 1 hour of operation left
Protection against misconnection	Over-voltage protection to 60 V dc (rated for 30 seconds)
Display	High contrast graphic liquid crystal display. LED backlighting for use in low lit areas.

PIE Thermocouple Calibrators Selection Guide
	PIE 520B	Lowest cost unit. Source only, 1 thermocouple type
	PIE 521B	Source only, 14 thermocouple types
	PIE 322	4 thermocouple types(J/K/T/E) Also includes screw connections for direct thermocouple wire connection. Comes with rubber boot and 2 pocket hands free case
	PIE 422	14 thermocouple types with secondary display of millivolts. Also includes screw connections for direct thermocouple wire connection. Comes with rubber boot and 2 pocket hands free case.
	PIE 422Plus	2 calibrators in 1! Source and Read, 14 thermocouple types with secondary display of milli- volts. Includes full milliamp loop calibrator(model 334Plus) which has patented current leak detection feature. Comes with rubber boot and 2 pocket hands free case

Process / Calibration/Temperature Calibration/Thermocouple Calibrators Template
Type	Hand Held
Measure Inputs	No
Source Outputs	Yes
Display (Thermocouple Calibrators)	Digital
Thermocouple Selection	E
T/C Source Accuracy	± 0.015% of Reading
T/C Source Resolution	0.1°
Battery Life	50 HR
Auto Step/Ramp	No
Backlit Display	Yes
Intrinsically Safe	No
Test Equipment General Attributes
Unique Features	Single TC Type - Works with type E One source replaces ALL the ranges for any single T/C type of the Altek 22
Warranty	3 YEARS
Warranty Details	3 Year Return to Factory warranty against defects in materials or workmanship.
Safety Approval	CE
Product Weight	8.4 OUNCES (0.525 LBS)
Product Height	1.8 IN
Product Length	5.00 IN
Product Width	2.75 IN
Shipping Weight	1.0 LBS
Data Logging	No
HTS/Schedule B Number	9030.39.0100
ECCN Number	EAR99
Calibration Included	Factory Calibration, NIST Calibration
Battery Type	AA
Power Supply Voltage	Battery Powered
Country of Origin	United States
