Record |
User configured 1 every 2 seconds to 1 every 24 hours
No. of Samples: 32,000 or 64,000 (depends on config) |
Record Trigger: |
Two independent triggers. Multiple trigger modes:
Instantaneous, button control, on alarm, time and date (start and stop), day of week |
Record Mode: |
Fill to end of memory, cyclic, number of samples, time duration |
Display: |
4 digit LCD (Non display versions available with LED only)
User programmable: Indication of data value, eng units, alarms,
record mode, battery condition, time/date, memory |
LED: |
User programmable: Indication of alarms, recording, triggered |
Button: |
User programmable: View display, record on/off, reset alarms, reset timer |
Alarms: |
2 user programmable alarms. High or Low |
Communication: |
Direct USB connection |
Software: |
Track-It™ Software—Program device, view data (historic or real time), export to Excel™. Simple and advanced modes |
Battery: |
Coin Cell Option: Battery: Lithium CR2032 Life: 1 year @ 1 minute sample rate
Hi Energy Option: Battery: EF651625 Life: 3 years @ 1 minute sample rate |
Measurement |
|
Temperature Range: |
-20 to +85°C / 0 to 185°F |
Accuracy: |
±1°C 0 to 50°C / 32 to 122°F ±2°C –20 to 85°C / 0 to 185 F |
Resolution: |
0.1°C / 0.1°F |
Clock Accuracy: |
±1 minute/year |
Available Analog Modules (for DC V/I) |
|
Range: |
0 to 500mV (no preconditioning) |
Accuracy: |
±0.5% of full scale |
Resolution: |
±0.1mV |
Input Modules |
500mV, 1V, 5V, 10V, 20mA |
