| General Specifications |
| Model |
ALE-223 |
ALE-323 |
ALE-623 |
| Capacity |
220g |
320g |
620g |
| Readability |
0.001 g, NTEP 0.01 g CLASS II |
| Calibration |
External calibration |
| Repeatability (Std. Dev.) |
± 0.001 g |
| Linearity |
±.0.001 g |
| Stabilization Time |
≤ 1.6 seconds |
| Weighing Units |
g, ct, lb, oz t, GN, dwt, mom, mg, oz |
| Functions |
Specific Gravity, Parts Counting (NTEP for pill counting only), %, Density, Checkweighing (limit function), Animal Weighing, GLP Compliant Formulation, Statistics, Accumulation, Below Balance Weighing |
| Tare Range |
To capacity by 100% subtraction |
| Power Source |
Input: AC/DC Adapter, 100 - 240 VAC, 50 - 60 Hz, Output: 6 VDC, Dry Cell Batteries (4 x AA, Not Included) |
| Construction |
Die cast aluminum base, ABS housing, Stainless Steel Platter, Anti-Static Glass Draft Shield |
| Display |
Large, easy to read 5/8” (16 mm) graphic LCD display with backlight and icons |
| Pan Size |
118 mm, 4.65” diameter |
| Draft Shield Internal Dimensions (W x D x H) |
5.9 x 5.9 x 7.87 inches / 150 x 150 x 200 mm |
| Overall Dimensions (W x D x H) |
7 x 9 x 3 inches / 180 x 230 x 75 mm (Not including draft shield) |
| Operating Environment |
41 °F to 95 °F / 5 °C to 35 °C
Temperature fluctuation ≤ 2 °C / hour
Humidity 50% to 85% RH |
| Connectivity |
USB Type B / DB-9 RS232 bi-directional interface |
| Net Weight |
2.86 lb / 1.3 kg |
| Shipping Weight |
6.5 lb / 2.94 kg |
| Options |
Ethernet or Relay Contact (only one option per unit), Specific Gravity Measurement Kit, Underweighing Hook, Carrying Case |
| Approvals |
NTEP C.o.C. #17-061A1 |
