| AC Current range |
42.00 to 1000 A AC, 3 ranges (±1.5 % rdg. ±5 dgt. at 50 or 60Hz), Average rectifier effective value |
| AC Voltage range |
4.200 to 600 V AC, 4 ranges (±2.3 % rdg. ±8 dgt. at 50 or 60Hz), Average rectifier effective value |
| DC Voltage range |
420.0 mV to 600 V DC, 5 ranges (±1.3 % rdg. ±4 dgt.) |
| Resistance |
420.0 to 42.00 M-ohm, 6 ranges |
| Accuracy |
±2.0 % rdg. ±4 dgt. (at 420 to 420 k-ohm range) |
| Continuity |
420.0 ohm (Buzzer sounds at approx. 50 ohm or less) |
| Frequency characteristics (at AC current / voltage) |
50 or 60 Hz |
| Display Section |
Digital / LCD, maximum 4199 dgt. |
| Max. Circuit Voltage |
600 V AC rms (insulated wire) |
| Power Supply |
CR2032 (3 VDC) × 1, Continuous use 150 hours |
| Dimensions |
57 mm(2.24 in)W × 175 mm(6.89 in)H × 16 mm(0.63 in)D |
| Accessories |
9208 TEST LEAD (1), 9398 CARRYING CASE (1) |
