| General Specifications |
| Sensor |
| Measurement Range |
In soil: 0 to 0.550 m³/m³ (volumetric water content) |
| Extended Range |
-0.401 to 2.574 m³/m³ |
| Accuracy |
±0.031 m³/m³ (±3.1%) typical 0 to 50°C (32° to 122°F) for mineral soils up to 8 dS/m and
±0.020 m³/m³ (±2%) with soil specific calibration; see Notes 2 and 3 |
| Resolution |
0.0007 m³/m³ (0.07%) |
| Volume of Influence |
0.3 liters (10.14 oz) |
| Sensor Frequency |
70 MHz |
| Sensor Operating Temperature Range |
0° to 50°C (32° to 122°F). Although the sensor probe and cable can safely operate at below-freezing temperatures (to -40°C/F),
the soil moisture data collected at these extreme temperatures is outside of the sensor's accurate measurement range. |
| Wireless Mote |
| Operating Temperature Range |
-25° to 60°C (-13° to 140°F) with rechargeable batteries
-40 to 70°C (-40 to 158°F) with lithium batteries |
| Radio Power |
12.6 mW (+11 dBm) non-adjustable |
| Transmission Range |
Reliable connection to 457.2 m (1,500 ft) line of sight at 1.8 m (6 ft) high
Reliable connection to 609.6 m (2,000 ft) line of sight at 3 m (10 ft) high |
| Wireless Data Standard |
IEEE 802.15.4 |
| Radio Operating Frequencies |
RXW-TMB-900: 904–924 MHz
RXW-TMB-868: 866.5 MHz
RXW-TMB-922: 916–924 MHz |
| Modulation Employed |
OQPSK (Offset Quadrature Phase Shift Keying) |
| Data Rate |
Up to 250 kbps, non-adjustable |
| Duty Cycle |
<1% |
| Maximum Number of Motes |
50 motes per one RX Wireless Sensor Network |
| Battery Type/ Power Source |
Two AA 1.2 V rechargeable NiMH batteries powered by built-in solar panel or two AA 1.5 V lithium batteries for operating
conditions of -40 to 70°C (-40 to 158°F) |
| Battery Life |
With NiMH batteries: Typical 3–5 years when operated in the temperature range -20° to 40°C (-4°F to 104°F) and positioned toward the sun
see Deployment and Mounting), operation outside this range will reduce the battery service life
With lithium batteries: 1 year, typical use |
| Memory |
16 MB |
| Dimensions |
Cable length: 5 m (16.4 ft)
Mote: 16.2 x 8.59 x 4.14 cm (6.38 x 3.38 x 1.63 inches) |
| Weight |
Mote: 223 g (7.87 oz) |
| Materials |
Sensor: Weatherproof
Mote: PCPBT, silicone rubber seal |
| Environmental Rating |
Mote: IP67, NEMA 6 |
| Compliance Marks |
RXW-TMB-900
RXW-TMB-868
RXW-TMB-922 |
