Pressure Sensor |
Operation range |
0 to 400 kPa (0 to 58 psia); approximately 0 to 30.6 m (0 to 100 ft) of water depth at sea level, or 0 to 33.6 m (0 to 111 ft) of water at 3,000 m (10,000 ft) of altitude |
Factory calibrated range |
69 to 400 kPa (10 to 58 psia), 0° to 40°C (32° to 104°F) |
Burst pressure |
500 kPa (72.5 psia) or 40.8 m (134 ft) depth |
Water level accuracy* |
Typical error - 0.05% FS, 1.5 cm (0.05 ft) water |
Maximum error |
- 0.1% FS, 3 cm (0.1 ft) water |
Raw pressure accuracy** |
0.3% FS, 1.20 kPa (0.17 psi) maximum error |
Resolution |
< 0.04 kPa (0.006 psi), 0.41 cm (0.013 ft) water |
Pressure response time 90% |
< 1 second |
Thermal response time (90%)† |
Approximately 10 minutes in water to achieve full temperature compensation of the pressure sensor |
* With accurate reference water level measurement and Barometric Compensation Assistant data |
** Absolute pressure sensor accuracy includes all pressure drift, temperature, and hysteresis-induced errors |
† Maximum error due to rapid thermal changes is approximately 0.5%. |
Temperature Sensor |
Accuracy Resolution Plot Operation range |
-20° to 50°C (-4° to 122°F) |
Accuracy |
0.37°C at 20°C (0.67°F at 68°F), see Plot A |
Resolution |
0.1°C at 20°C (0.18°F at 68°F) (10-bit), see Plot A |
Response time (90%) |
3.5 minutes in water (typical) |
Stability (drift) |
0.1°C (0.18°F) per year |
Logger |
Real-time clock |
± 1 minute per month 0° to 50°C (32° to 122°F) |
Battery |
2/3 AA, 3.6 Volt Lithium, factory-replaceable |
Battery life (typical use) |
5 years with 1 minute or greater logging interval |
Memory (non-volatile) |
64K bytes memory (approx. 21,700 pressure and temperature samples) |
Dimensions |
2.46 cm (0.97 inches) diameter, 15 cm (5.9 inches) length; mounting hole 6.3 mm (0.25 inches) diameter |
Weight |
Approximately 210 g (7.4 oz) |
Wetted materials |
316 stainless steel, Viton® o-rings, acetyl cap, ceramic sensor |
Shock/drop |
Logger is sensitive to shocks. Handle with care and avoid any impact. Always use proper packaging when shipping the logger. |
Logging interval |
Fixed-rate or multiple logging intervals, with up to 8 user-defined logging intervals and durations; logging intervals from 1 second to 18 hours. Refer to HOBOware software manual |
Launch modes |
Immediate start and delayed start |
Offload modes |
Offload while logging; stop and offload |
Battery indication |
Battery voltage can be viewed in status screen and optionally logged in datafile. Low battery indication in datafile |
The CE Marking identifies this product as complying with the relevant directives in the European Union (EU) |
