| Pressure Sensor |
| Operation range |
0 to 207 kPa (0 to 30 psia); approximately 0 to 9 m (0 to 30 ft) of water depth at sea level, or 0 to 12 m (0 to 40 ft) of water at 3,000 m (10,000 ft) of altitude |
| Factory calibrated range |
69 to 207 kPa (10 to 30 psia), 0° to 40°C (32° to 104°F) |
| Burst pressure |
310 kPa (45 psia) or 18 m (60 ft) depth |
| Water level accuracy* |
Typical error - 0.05% FS, 0.5 cm (0.015 ft) water |
| Maximum error |
- 0.1% FS, 1.0 cm (0.03 ft) water |
| Raw pressure accuracy** |
0.3% FS, 0.62 kPa (0.09 psi) maximum error |
| Resolution |
< 0.02 kPa (0.003 psi), 0.21 cm (0.007 ft) water |
| Pressure response time |
90% < 1 second |
| Thermal response time (90%)† |
Approximately 10 minutes in water to achieve full temperature compensation of the pressure sensor |
| * With accurate reference water level measurement and Barometric Compensation Assistant data |
| ** Absolute pressure sensor accuracy includes all pressure drift, temperature, and hysteresis-induced errors |
| † Maximum error due to rapid thermal changes is approximately 0.5% |
| Temperature Sensor |
| Operation range |
-20° to 50°C (-4° to 122°F) |
| Accuracy |
0.37°C at 20°C (0.67°F at 68°F), see Plot A |
| Resolution |
0.1°C at 20°C (0.18°F at 68°F) (10-bit) |
| Response time (90%) |
3.5 minutes in water (typical) |
| Stability (drift) |
0.1°C (0.18°F) per year |
| Logger |
| Real-time clock |
± 1 minute per month 0° to 50°C (32° to 122°F) |
| Battery |
2/3 AA, 3.6 Volt Lithium, factory-replaceable |
| Battery life (typical use) |
5 years with 1 minute or greater logging interval |
| Memory (non-volatile) |
64K bytes memory (approx. 21,700 pressure and temperature samples) |
| Dimensions |
2.46 cm (0.97 inches) diameter, 15 cm (5.9 inches) length; mounting hole 6.3 mm (0.25 inches) diameter |
| Weight |
Approximately 210 g (7.4 oz) |
| Wetted materials |
316 stainless steel, Viton® o-rings, acetyl cap, ceramic sensor |
| Shock/drop |
Logger is sensitive to shocks. Handle with care and avoid any impact. Always use proper packaging when shipping the logger |
| Logging interval |
Fixed-rate or multiple logging intervals, with up to 8 user-defined logging intervals and durations; logging intervals from 1 second to 18 hours |
| Launch modes |
Immediate start and delayed start |
| Offload modes |
Offload while logging; stop and offload |
| Battery indication |
Battery voltage can be viewed in status screen and optionally logged in datafile. Low battery indication in datafile |
| The CE Marking identifies this product as complying with the relevant directives in the European Union (EU) |
