FLIR CM82-NIST True RMS Power Clamp Meter with NIST Certificate

Name: FLIR CM82-NIST True RMS Power Clamp Meter with NIST Certificate
Brand: FLIR
SKU: FLIRCM82-NIST
Price: 549.00 USD
Availability: InStock

0 reviews | Catalog: CM82-NIST | UPC: 793950371824 | Model: FLIR CM82-NIST

FLIR_CM82-NIST_True_RMS_Power_Clamp_Meter_With_NIST_Certificate_Main_View

Compare

FLIR Industrial 600A Power Clamp with VFD Mode and NIST

NIST Certificate
VFD Mode: Accurately analyze non-sinusoidal waveforms and noisy signals in VFD-controlled equipment.
Phase Rotation: Analyze three-phase systems to measure power draw and verify if power is evenly balanced.
Inrush Current: Measure hard and soft start-up inrush current spikes while equipment is ramping up.
Power Factor and Active Power: Monitor power quality improvements, such as start-up realignments on three-phase equipment.
Harmonics Mode: Locate noise from different electrical draws to realign harmonics and reduce electro-mechanical equipment stress.
Rugged & Shock-Resistant: Double-molded case design and extra thick rubber on the corners absorbs shock to enhance job-site reliability and long-haul durability.
Bright Dual-LED Worklights: Make your work safer/easier in poorly lit locations- especially useful when the lights are out or obstacles block your inspection targets.

View Product Details

List Price: $549.00

In Stock:

View Payment Options

Recommended for you

Accessories

Choose a Category

for the FLIR CM82-NIST

FLIR TA11 Protective case for CM7x and CM8x Series

Catalog: TA11

(0)

In Stock!

Add to Cart

FLIR TA55 Universal AC Current Line splitter

Catalog: TA55

(0)

In Stock!

Add to Cart

HT Instruments LineSplitter Conductor Splitter Without Cable Stripping

Catalog: LineSplitter

(11)

In Stock!

Add to Cart

FLIR TA80 Universal CAT IV Silicone Test Probes

Catalog: TA80

(0)

In Stock!

Add to Cart

FLIR TA70 Universal CAT IV Insulated Alligator Test Probe Clips

Catalog: TA70

(0)

In Stock!

Add to Cart

TECHNICAL SUMMARY	CM82	CM83	CM85	BASIC ACCURACY
AC/DC Current	600A	600A	1000A	±2%
AC/DC Voltage	1000V	1000V	1000V	±1% / 0.7%
AC VFD Voltage	1000V	1000V	1000V	±1%
Harmonics	1st-25th Order	1st-25th Order	1st-25th Order	±5%
Total Harmonic Distortion	0.0 to 99.9%	0.0 to 99.9%	0.0 to 99.9%	±3%
Inrush Current	600ACA (Integration Time 100ms)	600ACA (Integration Time 100ms)	1000ACA (Integration Time 100ms)	±3%
Active Power	10kW to 600kW (10V, 5A min)	10kW to 600kW (10V, 5A min)	10kW to 1000kW (10V, 5A min)	±3%
Diode Test	0.4 to 0.8V	0.4 to 0.8V	0.4 to 0.8V	±0.1V
Capacitance	3.999mF	3.999mF	3.999mF	±1.9%
Resistance	99.99kΩ	99.99kΩ	99.99kΩ	±1%
Continuity Threshold	30Ω	30Ω	30Ω	±1%
Frequency	20.00Hz to 9.999kHz	20.00Hz to 9.999kHz	20.00Hz to 9.999kHz	±0.5%
Bluetooth Range Max	—	32ft (10m)	32ft (10m)	—
Jaw Opening	1.45in (37mm, 1000MCM)	1.45in (37mm, 1000MCM)	1.77in (45mm)	—
Category Rating	CAT IV-600V, CAT III-1000V
Battery Type	6 x AAA
Warranty	Limited Lifetime*

Tech Specs

Clamp Meters/Clamp Meters Template
True RMS	Yes
Maximum Current AC	600 A
Maximum Current DC	600 A
Maximum Voltage AC	1000 V
Maximum Conductor Size	1.4 IN
Resistance	Yes
Capacitance	Yes
Auto Ranging/Manual	Both
In-Rush Current	Yes
Test Equipment General Attributes
Unique Features	• FLIR Tools Mobile connects the FLIR CM83 to compatible smartphones and tablets via Bluetooth® for remote viewing and sharing • METERLiNK® technology wirelessly embeds electrical clamp meter readings into radiometric infrared images captured with compatible FLIR Thermal Cameras
Product Weight	20.8 OUNCES (1.3 LBS)
Product Height	1.9 IN
Product Length	10.3 IN
Product Width	3.9 IN
Shipping Weight	2.25 LBS
Calibration Included	NIST Calibration
Battery Type	AAA Battery Type 6 AAA
Power Supply Voltage	Battery Powered
Country of Origin	Taiwan
Shipping Height	12.6 IN
Shipping Length	5.5 IN
Shipping Width	5.5 IN
