Extech MA435T-NIST 400 A True RMS AC/DC Clamp Meter + NCV with NIST Calibration

Name: Extech MA435T-NIST 400 A True RMS AC/DC Clamp Meter + NCV with NIST Calibration
Brand: Extech
SKU: ExtechMA435T-NIST
Price: 249.36 USD
Availability: InStock

0 reviews | UPC: 793950374375 | Model: Extech MA435T-NIST

Extech MA435T-NIST 400A AC Clamp Meter plus NCV Detector

Compare

400A TRUE RMS AC/DC CLAMP METER WITH NIST- PLEASE NOTE: If not in stock: NIST calibration takes between 7-14 days once stock is available.

400A True RMS AC/DC Clamp Meter with NIST
True RMS for better accuracy when measuring distorted waveforms
Functions include: AC/DC Current, AC/DC Voltage, Resistance, Frequency, Capacitance, Temperature, Diode and Continuity
Built-in non-contact Voltage detector with LED alert
1.2" (30mm) jaw size for conductors up to 350MCM
Backlit LCD display
Data Hold, Auto Power Off and Low Battery indication
Complete with test leads, 9V battery, general purpose Type K bead wire temperature probe, and soft carrying case

View Product Details

List Price: $279.99

In Stock:

View Payment Options

Recommended for you

Accessories

Choose a Category

Line Splitters

for the Extech MA435T-NIST

HT Instruments LineSplitter Conductor Splitter Without Cable Stripping

Catalog: LineSplitter

(11)

In Stock!

Add to Cart

400A True RMS AC/DC Clamp Meter with NIST
Compact Size AC Clamp Meter with 10 Functions

The Extech MA435T-NIST is a compact 400A AC clamp meter with NIST that enables users to take measurements in tight spaces while offering an ample 1.2-inch (30mm) jaw opening to accommodate conductors up to 350 MCM. The MA435T also features True RMS for better accuracy when measuring distorted waveforms; a large four-digit readout and illuminated display that enhances viewing in poorly lit work areas; and a thumb-dial selector that facilitates convenient, one-handed operation.

Extech MA430 Series Clamp Meters
Model	MA430/MA430T	MA435T	Basic Accuracy
Display counts	2000	4000
True RMS	— / Yes	Yes
AC Current (max res.)	400A (0.001A)	400A (0.01A)	±(2.5% + 8d)
DC Current (max res.)	-	400A (0.01A)	±(2.5% + 5d)
AC Voltage (max res.)	600V (0.1mV)	600V (0.1mV)	±(1.5% + 5d)
DC Voltage (max res.)	600V (0.1mV)	600V (0.1mV)	±(1.5% + 2d)
Resistance (max res.)	20MΩ (0.1Ω)	40MΩ (0.1Ω)	±(1.5% + 2d)
Frequency (max res.)	-	10Hz to 10kHz	±(1.5% + 2d)
Capacitance (max res.)	-	100µF (0.01nF)	±(3.0% + 5d)
Temperature (max res.)	-	-4 to 1400°F/-20 to 760°C (0.1°)	±(3% + 9°F/5°C)
Diode/ Continuity	Yes	Yes
Dimensions/ Weight	7.8x2.8x1.6" (197x70x40mm)/ 6.5oz (183g)
General Specifications
Function	Range	Resolution	Accuracy (% of reading + digits)
AC Current* 50/60Hz TRMS	40.00 A	0.01A	±(2.8% + 8 digits)
AC Current* 50/60Hz TRMS	400.0 A	0.1A	±(2.8% + 8 digits)
DC Current	40.00 A	0.01A	±(2.5% + 5 digits)
DC Current	400.0 A	0.1A	±(2.8% + 5 digits)
AC Voltage* 50/60Hz TRMS	400.0mV	0.1mV	±(1.5% + 30 digits)
	4.000 V	0.001V	±(1.5% + 8 digits)
	40.00 V	0.01V
	400.0 V	0.1V
	600 V	1V	±(2.5% + 5 digits)
DC Voltage	400.0 mV	0.1mV	±(0.8% + 2 digits)
	4.000 V	0.001V	±(1.5% + 2 digits)
	40.00 V	0.01V
	400.0 V	0.1V
	600 V	1V	±(2.0% + 2 digits)
Resistance	400.0Ω	0.1Ω	±(1.0% + 4 digits)
	4.000kΩ	0.001kΩ	±(1.5% + 2 digits)
	40.00kΩ	0.01kΩ
	400.0kΩ	0.1kΩ
	4.000MΩ	0.001MΩ	±(2.5% + 3 digits)
	40.00MΩ	0.01MΩ	±(3.5% + 5 digits)
Capacitance	40.00nF	0.01nF	±(4.0% + 20 digits)
	400.0nF	0.1nF	±(3.0% + 5 digits)
	4.000μF	0.001μF
	40.00μF	0.01μF
	100.0μF	0.1μF	±(4.0% + 10 digits)
Frequency	10 to 10kHz	0.01Hz	±(1.5% + 2 digits)
Sensitivity	100V(<50Hz);	50V(50 to 400Hz);	15V(401Hz to 10kHz)
Duty Cycle	0.5% to 99.0%	0.1%	±(1.2% + 2 digits)
Duty Cycle	Pulse width: 100Ωs to 100ms, Frequency: 10Hz to 10kHz
Temperature Type K	-4.0 to 1400°F -20 to 760°C	0.1° <400° 1° >400°	±(3% + 9°F/5°C)
Temperature Type K	Specification does not include probe accuracy. Range of supplied probe is -22 to 572°F (-30 to 300°C).

Tech Specs

Test Equipment General Attributes
Product Weight	6.5 LBS
Product Height	1.6 IN
Product Length	7.8 IN
Product Width	2.8 IN
Country of Origin	China
