AC volts |
400mV, 4V, 40V, 400V, 750V |
|
Accuracy 4V, 40V, 400V |
±(0.8% + 3 dgts) |
|
Accuracy 400mV, 750V |
±(1.2% + 3 dgts) |
|
DC volts |
400mV, 4V, 40V, 400V, 1000V |
|
Accuracy 400mV, 4V, 40V, 400V |
±(0.5% + 3 dgts) |
|
Accuracy 1000V |
±(0.8% + 3 dgts) |
|
AC current |
40µA, 400µA, 4000µA, 40mA, 400mA, 10A |
|
Accuracy 40µA, 400µA, 4000µA |
±(1.5% + 5 dgts) |
|
Accuracy 40mA, 400mA |
±(2% + 5 dgts) |
|
Accuracy 10A |
±(2.5% + 5 dgts) |
|
DC current |
40µA, 400µA, 4000µA, 40mA, 400mA, 10A |
|
Accuracy 40µA, 400µA, 4000µA |
±(1.2% + 3 dgts) |
|
Accuracy 40mA, 400mA |
±(1.5% + 3 dgts) |
|
Accuracy 10A |
±(2% + 5 dgts) |
|
Resistance |
400O, 4kO, 40kO, 400kO, 4MO, 40MO, 400MO |
|
Accuracy 400O, 4kO, 40kO, 400kO, 4MO |
±(1%+3 dgts) |
|
Accuracy 40MO |
±(2%+3 dgts) |
|
Accuracy 400MO |
±(3%+10 dgts) |
|
Capacitance |
4nF, 40nF, 400nF, 4µF, 40µF, 200µF |
|
Accuracy 4nF |
±(5%+10 dgts) |
|
Accuracy 40nF |
±(3%+10 dgts) |
|
Accuracy 400nF, 4µF, 40µF |
±(2%+5 dgts) |
|
Accuracy 200µF |
±(4%+5 dgts) |
|
Frequency |
10Hz - 15MHz ±(0.1% + 5) |
|
Sensitivity |
Sine wave 0.6Vrms |
|
Accessories |
Heavy-duty test leads, holster, manual, & 9V battery included |
|
Dimensions |
7 1/2” (H) x 3 1/2” (W) x 1 3/4” (D) (without holster) |
|
Weight |
10.56 oz. (without holster) |
