Elenco GF-800_555 20Hz - 150kHz Low Distortion Sine/Square Wave Audio Generator

Name: Elenco GF-800_555 20Hz - 150kHz Low Distortion Sine/Square Wave Audio Generator
Brand: Elenco
SKU: ElencoGF-800_555
Availability: InStock

0 reviews | Model: Elenco GF-800_555

Compare

Sine/Square Wave Audio Generator

Sine and square wave generator
20Hz to 150kHz in 46 steps
Low distortion R-C oscillator
Variable output control
Low battery indicator
Compact portable, lightweight

View Product Details

In Stock:

View Payment Options

Recommended for you

Accessories

Choose a Category

Adapter Kits

for the Elenco GF-800_555

Cal Test CT4103 Universal Adapter Kit

Catalog: CT4103

(9)

In Stock!

Add to Cart

Frequency range	x1 range 20Hz to 1.5kHz (23 steps), x100 range 2kHz to 150kHz (23 steps)
Accuracy	20Hz through 100kHz (+3% or less), 120kHz and 150kHz (+5% or less)
Output control	0dB/-20dB attenuator switch and variable amplitude control
Output impedance	approximately 600O
SINEWAVE CHARACTERISTICS
Output voltage	>1.2V rms at max. setting (no load)
Output flatness	(short term) 20Hz to 150kHz +0.5dB (reference frequency 1kHz)
Distortion	200Hz - 15kHz <0.05% 15kHz-150kHz <0.3%
SQUARE WAVE CHARACTERISTICS
Output voltage	>5V p-p at maximum setting
Rise & fall time	Less than 0.5µs
Sag	Less than 5% at 20Hz (DC coupled)
Over shoot	<2% from maximum output
Duty ratio	50% +5%
SYNCHRONIZATION CHARACTERISTICS
Output voltage	>1.2 rms (no load)
Output impedance	1kO +5%
