Autonics SPA-075-12 - Switching Power Supply, 12 VDC output, 75 Watts

Name: Autonics SPA-075-12 - Switching Power Supply, 12 VDC output, 75 Watts
Brand: Autonics
SKU: AutonicsSPA-075-12
Price: 155.00 USD
Availability: InStock

0 reviews | Model: Autonics SPA-075-12

Autonics SPA Series Switching Mode Power Supply

Compare

Power Supply, Switching, 12 VDC output, 75 Watts, 6.3 Amp 100-240 VAC Input

Output power: 75W
Input Voltage: 100-120/200-240VAC~50/60Hz~
Permissible voltage: 85-132/170-264VAC~50/60Hz
Output_Voltage: 12VDC
Output_Current: 6.3A
Mounting type: Using Bolts

View Product Details

Your Price: $155.00

Sign-in for EDU Pricing!

In Stock:

Free shipping over $99 - Code: FREESHIP
Please note, FREE SHIPPING is only available on items that can ship via standard ground shipping and is only valid within the Contiguous United States. Any items that must ship via freight or to any destination outside of the Contiguous United States will be excluded. - USE CODE FREESHIP at checkout

Valid on Web Price Only!
View Payment Options

Request Quote

Items in This Series



Product	Autonics SPA-075-12 Power Supply, Switching, 12 VDC output, 75 Watts, 6.3 Amp 100-240 VAC ...	Autonics SPA-030-24 Power Supply, Switching, 24 VDC Output, 30 Watts, 1.5 Amp 100-240 VAC ...	Autonics SPA-030-12 Power Supply, Switching, 12 VDC output,30 Watts, 2.5 Amp 100-240 VAC I ...	Autonics SPA-050-24 Power Supply, Switching, 24 VDC output, 50 Watts, 2.1 Amp 100-240 VAC ...	Autonics SPA-050-12 Power Supply, Switching, 12 VDC Output, 50 Watts, 4.2 Amp 100-240 VAC ...	Autonics SPA-075-24 Power Supply, Switching, 24 VDC output, 75 Watts, 3.2 Amp 100-240 VAC ...	Autonics SPA-075-05 Power Supply, Switching, 5 VDC output, 75 Watts, 15 Amp 100-240 VAC In ...	Autonics SPA-100-24 Power Supply, Switching, 24 VDC output, 100 Watts, 4.2 Amp 100-240 VAC ...	Autonics SPA-100-05 Power supply, Switching, 5VDC Output, 100Watts, 20A, 100-240VAC Input	Autonics SPA-400-24 Switching Mode Power Supply, 400W, 24VDC
Price
In Stock
Compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare

Recommended for you

Autonics SPA-075-12 Accessories

Choose a Category

Power Supply Kits

for the Autonics SPA-075-12

Cal Test CT4041 Power Supply Accessory Kit ( rated for up to 20amps ) Get the most...

Catalog: CT4041

(24)

In Stock!

Add to Cart

Autonics SPA-075-12 - Switching Power Supply, 12 VDC output, 75 Watts

Panel Mount Switching Mode Power Supply

Output power: 75W
Input Voltage: 100-120/200-240VAC~50/60Hz~
Permissible voltage: 85-132/170-264VAC~50/60Hz
Output_Voltage: 12VDC
Output_Current: 6.3A
Mounting type: Using Bolts

The SPA series switching mode power supplies provide efficient power conversion and stable power supply with minimal noise and ripple. Various output voltage (5 VDC, 12 VDC, 24 VDC) and output power (30 W, 50 W, 75 W, 100 W, 400 W) models are available for diverse applications. The SPA series also features built-in overcurrent protection circuit, output short-circuit protection circuit, overheat protection circuit, and overvoltage protection circuits.

Stable power supply with minimal noise and ripple
Built-in overcurrent protection circuit, output short-circuit protection circuit, overheat protection circuit, and overvoltage protection circuits (overvoltage protection: SPA-075/100 only)
EN 60950 (Safety of information technology equipment) compliant
EN 50178 (Electronic equipment for use in power installations) compliant
EN 61000-6-2 (EMC: immunity for industrial environments) compliant
EN 61000-6-4 (EMC: emission standard for industrial environments) compliant
Output voltage: 5VDC, 12VDC, 24VDC
Output power: 30 W, 50 W, 75 W, 100 W, 400 W

Autonics SPA Series Specifications
Model		SPA-030-05	SPA-050-05	SPA-030-12	SPA-050-12	SPA-030-24	SPA-050-24
Output power		30W	50W	30W	50W	30W	50W
Input
Voltage^*6		100-240VAC (permissible voltage: 85-264VAC)
Frequency		50/60Hz
Efficiency^*1		Min. 60%	Min. 67%	Min. 74%		Min. 80%
Current consumption^*1		Max. 1.2A	Max. 1.6A	Max. 1.0A	Max. 1.4A	Max. 0.8A	Max. 1.1A
Output
Voltage		5VDC		12VDC		24VDC
Current		6A	10A	2.5A	4.2A	1.5A	2.1A
Voltage adjustment range^*4		±5%
Input fluctuation ratio^*2		Max. ±0.5%
Load fluctuation ratio^*1		Max. ±2%		Max. ±1%
Ripple^*1		Max. ±1%
Starting time^*1		Max. 200ms		Max. 150ms
Holding time^*1		Min. 10ms
Protection
Inrush current protection		Max. 30A (100VAC) /Max. 40A (200VAC)		Max. 20A (100VAC)
Over-current protection^*3		Min. 110%
Over-voltage protection		—
Output short-circuit protection		Max. 5ms
Indicator		Output indicator: Green LED
Insulation resistance		Over 100MΩ (between all input and output terminals with 500VDC)
Dielectric strength		3,000VAC 50/60Hz for 1 min (between all input and output terminals)
		1,500VAC 50/60Hz for 1 min (between all input terminals F.G.)
Vibration		0.75mm amplitude at frequency of 10 to 55Hz (for 1 min) in each X, Y, Z direction for 2 hours
Shock		300m/s² (approx. 30G) in each X, Y, Z direction for 3 times
EMS		Conforms to EN61000-6-2
EMI		Conforms to EN61000-6-4
Safety standards		EN60950, EN50178
Environment	Ambient temperature	-10 to 50°C	-10 to 40°C			-10 to 50°C
	Storage temperature	-25 to 65°C
	Ambient humidity	25 to 85%RH, storage: 25 to 90%RH
Unit weight		Approx. 350g
1: 100% load for rated input voltage (100VAC). 2: Rated input voltage •SPA-030/050 Series: 100-240VAC (85-264VAC) •SPA-075/100 Series: 100-120/200-240 (85-132/170-264VAC) under 100% of load. SPA-100-05 is under 100% of load for [100-120/200-240VAC (100-132/190-264VAC)]. 3: Rated input voltage (100VAC). 4: Vary voltage by output voltage adjuster, it is changed over voltage variation range (±5%). 5: The rated input volatge of SPA-100-05 is 100-120/200-240VAC (100-132/190-264VAC). Environment resistance is rated at no freezing or condensation.

Model		SPA-075-05	SPA-100-05	SPA-075-12	SPA-100-12	SPA-075-24	SPA-100-24
Output power		75W	100W	75W	100W	75W	100W
Input
Voltage^*6		100-120/200-240VAC (permissible voltage: 85-132/170-264VAC) switching type
Frequency		50/60Hz
Efficiency^*1		Min. 70%		Min. 78%	Min. 72%	Min. 78%	Min. 80%
Current consumption^*1		Max. 3.0A		Max. 2.0A	Max. 3.0A	Max. 2.0A	Max. 2.5A
Output
Voltage		5VDC		12VDC		24VDC
Current		15A	20A	6.3A	8.5A	3.2A	4.2A
Voltage adjustment range^*4		±5%
Input fluctuation ratio^*2		Max. ±0.5%
Load fluctuation ratio^*1		Max. ±2%		Max. ±1%
Ripple^*1		Max. ±1%
Starting time^*1		Max. 250ms
Holding time^*1		Min. 5ms		Min. 10ms	Min. 5ms	Min. 10ms
Protection
Inrush current protection		Max. 45A (100VAC) /Max. 50A (240VAC)		Max. 35A (100VAC) /Max. 40A (240VAC)	Max. 45A (100VAC) /Max. 50A (240VAC)	Max. 35A (100VAC) /Max. 40A (240VAC)
Over-current protection^*3		Min. 110%	Min. 105%	Min. 110%
Over-voltage protection		6.5V ±10%		16V ±10%		30V ±10%
Output short-circuit protection		Max. 10ms		Max. 5ms	Min. 10ms	Max. 5ms
Indicator		Output indicator: Green LED
Insulation resistance		Over 100MΩ (between all input and output terminals with 500VDC)
Dielectric strength		3,000VAC 50/60Hz for 1 min (between all input and output terminals)
		1,500VAC 50/60Hz for 1 min (between all input terminals F.G.)
Vibration		0.75mm amplitude at frequency of 10 to 55Hz (for 1 min) in each X, Y, Z direction for 2 hours
Shock		300m/s² (approx. 30G) in each X, Y, Z direction for 3 times
EMS		Conforms to EN61000-6-2
EMI		Conforms to EN61000-6-4
Safety standards		EN60950, EN50178
Environment	Ambient temperature	-10 to 50°C
	Storage temperature	-25 to 65°C
	Ambient humidity	25 to 85%RH, storage: 25 to 90%RH
Unit weight		Approx. 400g
1: 100% load for rated input voltage (100VAC). 2: Rated input voltage •SPA-030/050 Series: 100-240VAC (85-264VAC) •SPA-075/100 Series: 100-120/200-240 (85-132/170-264VAC) under 100% of load. SPA-100-05 is under 100% of load for [100-120/200-240VAC (100-132/190-264VAC)]. 3: Rated input voltage (100VAC). 4: Vary voltage by output voltage adjuster, it is changed over voltage variation range (±5%). 5: The rated input volatge of SPA-100-05 is 100-120/200-240VAC (100-132/190-264VAC). Environment resistance is rated at no freezing or condensation.

Tech Specs

Test Equipment General Attributes
Country of Origin	Korea
