| Display method |
Non-display |
| Number of input channels |
2-channel |
| Input specification |
Thermocouple: K(CA), J(IC), E(CR), T(CC), B(PR), R(PR), S(PR), N(NN), C(TT), G(TT), L(IC), U(CC), Platinel II
RTD: DPt100Ω, DPt50Ω, JPt100Ω, Cu100Ω, Cu50Ω, Nickel120Ω
Analog: -60-60mV, 0-200mV, 0-1V, 1-5V, 0-5V, 0-10V, 0-20mA, 4-20mA |
| Sampling cycle |
50ms(2-CH synchronous sampling) |
| Power supply |
5VDC USB bus power |
| Protection structure |
IP20 |
| Approval |
CE IC |
| Communication type |
USB |
| Protocol |
Modbus RTU |
| Display accuracy_RTD |
ㆍAt room temperature range (23℃±5℃) : (PV ±0.3% or ±1℃, select the higher one) ±1-digit
ㆍOut of room temperature range : (PV ±0.5% or ±2℃, select the higher one) ±1-digit |
| Display accuracy_Thermocouple |
ㆍAt room temperature range (23℃±5℃) : (PV ±0.3% or ±1℃, select the higher one) ±1-digit
ㆍOut of room temperature range : (PV ±0.5% or ±2℃, select the higher one) ±1-digit |
| Display accuracy_Analog |
ㆍAt room temperature range (23℃±5℃): ±0.3% F.S. ±1-digit
ㆍOut of room temperature range: ±0.5% F.S. ±1-digit |
| Insulation type |
Double insulation or reinforced insulation |
| Mounting type |
DIN rail or panel mounting |
| Accessories |
USB 2.0 AB type cable: 1 (length: 1m) |
| Environment_Ambient temperature |
-10 to 50℃, storage: -20 to 60℃ |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Weight |
Approx. 195g (approx. 140g) |
