Autonics S3KF-3ES2A 30 mm Key Selector Switch

Name: Autonics S3KF-3ES2A 30 mm Key Selector Switch
Brand: Autonics
SKU: AutonicsS3KF-3ES2A
Availability: InStock

0 reviews | Model: Autonics S3KF-3ES2A

Compare

Key Selector, Flush, 30, 3 Positions Spring Return, Two way key removal : Center, Gray, 2 Normal Open, 110VAC/10A,220VAC/5A

Operation type: 3-position, spring return two-way
Key removal position: Center
Color: Silver
Contact block: A contact: 2
Contact block type: Singular type

View Product Details

In Stock:

Free shipping over $99 - Code: FREESHIP
Please note, FREE SHIPPING is only available on items that can ship via standard ground shipping and is only valid within the Contiguous United States. Any items that must ship via freight or to any destination outside of the Contiguous United States will be excluded. - USE CODE FREESHIP at checkout

Valid on Web Price Only!
View Payment Options

Call Us

Request Quote

Items in This Series



Product	Autonics S3KF-3ES2A Key Selector, Flush, 30, 3 Positions Spring Return, Two way key remova ...	Autonics S3KF-2ESAM Key Selector, Flush, 30, 2 Positions Maintained, Center Key Withdarw P ...	Autonics S3KF-4CSABM Key Selector, Flush, 30, 3 Positions Maintained, Left + Center + Righ ...	Autonics S3KF-1ES Key Selector, Flush, 30, 2 Positions Spring Return, Center Key Withdarw ...	Autonics S3KF-1ESA Key Selector, Flush, 30, 2 Positions Spring Return, Center Key Withdarw ...	Autonics S3KF-1ESABM Key Selector, Flush, 30, 2 Positions Spring Return, Center Key Withda ...	Autonics S3KF-1ESB Key Selector, Flush, 30, 2 Positions Spring Return, Center Key Withdarw ...	Autonics S3KF-2ES Key Selector, Flush, 30, 2 Positions Maintained, Center Key Withdarw Pos ...	Autonics S3KF-2FS Key Selector, Flush, 30, Positions Maintained, Center + Right Key Withda ...	Autonics S3KF-3ES Key Selector, Flush, 30, 3 Positions Spring Return, Two way key removal ...	Autonics S3KF-4CS Key Selector, Flush, 30, 3 Positions Maintained, Left + Center + Right K ...	Autonics S3KF-5GS Key Selector, Flush, 30, 3 Positions Spring Return From Right, Left + Ce ...
Price
In Stock
Compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare

Recommended for you

Contact block_Electrical specification_Power voltage/current	110VAC~/10A, 250VAC~/6A
Protection structure	IP52
Approval
Weight_Mounting hole_Ø30	Approx. 41g
Weight_Housing	Approx. 7g
Weight_Contact block_Singular type A/B contact	Approx. 11g
Operation type	3-position, spring return two-way
Key removal position	Center
Color	Silver
Contact block	A contact: 2
Contact block type	Singular type
Environment_Ambient temperature	-15 to 55℃, storage: -25 to 65℃
Environment_Ambient humidity	35 to 85% RH, storage: 35 to 85% RH

※Environment resistance is rated no freezing or condensation.
※The control unit, contact blocks, LED blocks are sold separately.
※Connect up to 2 contact blocks. Connect the contact blocks only on the right and left side slots. It will not operate if connected to the center slot.
