Autonics S2ER-E4R Emergency Stops

Name: Autonics S2ER-E4R Emergency Stops
Brand: Autonics
SKU: AutonicsS2ER-E4R
Price: 3.00 USD
Availability: InStock
Rating: 5.00 (1 reviews)

5 (1 Review) | Model: Autonics S2ER-E4R

Compare

Emergency Stops diameter 22/25, RED, Head diameter 40(Short Head), Illuminated

Emergency Stops diameter 22/25, RED, Head diameter 40(Short Head), Illuminated
Smooth operation
High electrical conductivity
Long-lasting durability

View Product Details

Your Price: $3.00

Sign-in for EDU Pricing!

In Stock:

Free shipping over $99 - Code: FREESHIP
Please note, FREE SHIPPING is only available on items that can ship via standard ground shipping and is only valid within the Contiguous United States. Any items that must ship via freight or to any destination outside of the Contiguous United States will be excluded. - USE CODE FREESHIP at checkout

Valid on Web Price Only!
View Payment Options

Request Quote

Items in This Series



Product	Autonics S2ER-E4R Emergency Stops diameter 22/25, RED, Head diameter 40(Short Head), Illum ...	Autonics S2ER-E4R2BL Illuminated Emergency Stops 2/25, RED, Haed 40, 2 Normal Close, LED 1 ...	Autonics S2ER-E4RABD Illuminated Emergency Stops 2/25, RED, Haed 40, 1 Normal Open, 1 Norm ...	Autonics S2ER-E4RABL Illuminated Emergency Stops 2/25, RED, Haed 40, 1 Normal Open, 1 Norm ...	Autonics S2ER-E4RBD Illuminated Emergency Stops 2/25, RED, Haed 40, 1 Normal Close, LED 12 ...	Autonics S2ER-E4RBL Illuminated Emergency Stops 2/25, RED, Haed 40, 1 Normal Close, LED 10 ...	Autonics S2ER-E4R2BD Illuminated Emergency Stops 22/25, RED, Head 40, 2 Normal Close, LED ...	Autonics S2ER-E4RAD Illuminated Emergency Stops 22/25, RED, Head 40, 1 Normal Open, LED 12 ...	Autonics S2ER-E4RAL Illuminated Emergency Stops 22/25, RED, Head 40, 1 Normal Open, LED 10 ...	Autonics S2ER-E4RBLM Illuminated Emergency Stops diameter 22/25, RED, Head diameter 40, 1 ...	Autonics S2ER-E4R2AD Illuminated Emergency Stops 22/25, RED, Head 40, 2 Normal Open, LED 1 ...	Autonics S2ER-E4R2AL Illuminated Emergency Stops 22/25, RED, Head 40, 2 Normal Open, LED 1 ...
Price
In Stock
Compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare

Recommended for you

Autonics S2ER Series 22/25 mm Emergency Switches

The S2ER series Ø22/25 mm emergency switches are available in short/long head types with different switch head sizes so that it can be applied in various environments requiring stop control.

Smooth operation
Long-lasting durability
Outstanding performance

Applications

Chip Bag Filling, Sealing, and Cutting Key selector switches and lever selector switches are used to control operations such as RUN/STOP and AUTO/MANUAL modes. Emergency switches are used to stop the machinery during emergencies.	Escalator Drive Operation Emergency switches installed on escalators can be used to stop operation of the escalator in the event of an emergency (falling, entrapments, etc.).

Dimension

General Specifications
Contact block_Electrical specification_Power voltage/current	110VAC~/10A, 250VAC~/6A
LED block_Power supply	12-24VAC~ 50/60Hz, 12-24VDC
LED block_Current consumption	Max. 20mA
Protection structure	IP52
Approval
Weight_Mounting hole_Ø22/25	Approx. 22.5g
Weight_Housing	Approx. 7g
Weight_Contact block_Singular type A/B contact	Approx. 11g
Weight_LED block_AC/DC voltage type	Approx. 11g
Operation type	Push-lock, Turn-reset
Button type	D40(short head, illuminated)
Color	Red
Contact block	B contact: 2
Contact block type	Singular type
Environment_Ambient temperature	-15 to 55℃, storage: -25 to 65℃
Environment_Ambient humidity	35 to 85% RH, storage: 35 to 85% RH
※Environment resistance is rated no freezing or condensation. ※The control unit, contact blocks, LED blocks are sold separately.
