Autonics MS86S-S00-R - D86mm Xenon lamp Strobe Light, Red Lens, 12-24 Volt AC/DC

Name: Autonics MS86S-S00-R - D86mm Xenon lamp Strobe Light, Red Lens, 12-24 Volt AC/DC
Brand: Autonics
SKU: AutonicsMS86S-S00-R
Price: 103.00 USD
Availability: InStock

0 reviews | Model: Autonics MS86S-S00-R

Compare

Light, Strobe, 86mm, Stud Mount, Red Lens, 12-24 Volt AC/DC

Internal molding type, Blue Lens, 12-24 Volt AC/DC
Xenon light
Wide light distribution with prism-cut dome-shaped lens
Outstanding visibility at distance
PCB module style Xenon lamp
Fast and easy replacement of lamp
IP65 rated

View Product Details

Your Price: $103.00

Sign-in for EDU Pricing!

In Stock:

Free shipping over $99 - Code: FREESHIP
Please note, FREE SHIPPING is only available on items that can ship via standard ground shipping and is only valid within the Contiguous United States. Any items that must ship via freight or to any destination outside of the Contiguous United States will be excluded. - USE CODE FREESHIP at checkout

Valid on Web Price Only!
View Payment Options

Request Quote

Items in This Series



Product	Autonics MS86S-S00-R Light, Strobe, 86mm, Stud Mount, Red Lens, 12-24 Volt AC/DC	Autonics MS86S-N20-R Light, Strobe, 86mm, Stud Mount, Red Lens, 220 VAC
Price
In Stock
Compare	Add to compare	Add to compare

Recommended for you

Autonics MS86S-S00-R

Wide light distribution with prism-cut dome-shaped lens
Outstanding visibility at distance
PCB module style Xenon lamp
Fast and easy replacement of lamp
IP65 rated

Light, Strobe, 86mm, Stud Mount, Red Lens, 12-24 Volt AC/DC

The MS86S Series strobe light of high brightness, Excellent visibility from a distance improving visibility by employing special scattering lens. Fast and easy replacement of lamp with IP65 rated.

General Specification
Function	Flashing
Power supply	220VAC
Current consumption	0.03A
Light source	Xenon lamp 6W
Lens color	Red
Dimension	D86mm
Flashing rate	80±10times/minute
Mounting direction	Body direct mounting
Connection type	Lead wire connection
Cable specification	UL2464/22AWG×2C
Ambient temperature	-20~40℃
Storage ambient temperature	-20~70℃
Ambient humidity	45 to 85%RH
Insulation resistance	100MΩ or more (500VDC megger basis)
Vibration	0.75mm at 10~55Hz
Protection structure	IP65
Weight	Approx. 200g
