DC Voltage: 400.0mV/4.000/40.00/400.0/600V ±(1.0% Rdg + 2 LSD) AC Voltage: 400.0mV ±(1.0%Rdg + 50 LSD) 4.000/40.00/400.0/600V ±(1.2% Rdg + 3 LSD) AC/DC Current: 40.00/400.0A ±(2% Rdg + 10 LSD) @50 - 60hz Resistance: 400.0?, 4.000/40.00/400.0k? ±(1% Rdg + 5 LSD) 4.000/40.00M? ±(3% Rdg + 3 LSD) Comply with: EN 61010 Insulation: Class 2, double reinforced insulation Pollution: Level 2 For inside use, max height: 2000m Over voltage: CAT III 600V (between ground & input terminal) Size: 205(L) x 64 (W) x 39(H)mm Weight (including battery): about 280g Jaws opening: 30mm Max conductor size: 30mm Batteries type: 2 batteries 1.5V LR03 AAA. Low battery indication: Symbol " " is displayed when battery level is too low. Battery life: About 25 hours. Display Characteristics: 3 _ LCD w/ maximum reading 3999 units plus decimal point signs plus backlight Sample rate: 2 times/sec. 20 times/sec. for analogical bargraph Conversion mode: mean value Reference temperature: 23° ± 5°C Operating temperature: 5 ÷ 40 °C Operating humidity: 80% RH Storage temperature: -10 ÷ 60 °C Storage humidity: 80% RH EMC: This apparatus was designed in accordance with EMC standards in force and its compatibility has been tested in accordance EN61326 (1997) + A1 (1998) + A2 (2001). The accessories contained inside the packaging are the following: Instrument, Test leads (MTL-90B), Rubber test lead holster (MTL-CAP), User?s manual, Carrying case (SV-U), Batteries |
