Display: 3-3/4 digits 4000 counts LCD display Update Rate: 3 per second nominal Polarity: Automatic Operating Temperature: 0 ?C to 40 ?C; 80% RH for temperature up to 31 ?C decreasing linearly to 50% RH at 40 ?C Altitude: Operating below 2000m; Indoor use Storage Temperature: -20 ?C to 60 ?C, 80% RH (with battery removed) Temperature Coefficient: nominal 0.15 x (specified accuracy)/?C @(0 ?C ~ 18 ?C or 28 ?C ~ 40 ?C) Low Battery: Below approx. 2.4V Power Supply: 3V coin battery IEC-CR2032 Power Consumption: 2.8 mA typical except that 3.3 mA typical for ACA function APO Timing: Idle for 30 minutes APO Consumption: 5 µA typical Dimension: 190 x 63 x 32 mm (7.4 x 2.5 x 1.3 in) Weight: 139 gm approx Jaw opening & Conductor diameter: max 26 mm Special Features: 30ms Max Hold; Data Hold; Relative Zero mode Safety: Meets EN61010-2-032, UL61010B-2-032, IEC61010-1 2nd Ed., EN61010-1 2nd Ed., UL61010-1 2nd Ed. CAT III-600 Volts ac & dc; Pollution degree - 2 EMC: Conforms to EN61326-1. |
