AEMC 2110.79 - AC Current Probe Model JM800A

The Model JM800A is a high performance AC current probe for higher currents. Excellent transformation and low phase shift, plus a broad frequency response, permit accurate measurements of current and power. The high quality magnetic core and uniform windings provide for accurate measurements up to 1500AAC. The “squared” jaw permits multiple conductor or bus bar positioning.

The Model JM800A provides excellent True RMS capabilities and reliable signal reproduction. The Model JM800A works as a traditional current transformer providing current outputs (mA) over a broad range of transformation ratios. The Model JM800A is designed for use on DMMs, power and harmonic meters, recorders, or instruments with AC current ranges.

Applications

• Electrical utility
• HVAC
• Industrial maintenance
• Laboratory
• Plant maintenance
