Rigol Sigilent SDS1102CML vs Rigol DS1102E Digital Oscilloscopes




Comparison of the Sigilent SDS1102CML and the Rigol DS1102E Digital Oscilloscopes:


Sigilent SDS1102CML is a 2 channel, 100 MHz digital oscilloscope that comes with 2 Mpnts of memory, up to 1 GS/s sampling rates, and a large 7 inch screen. Data as well as waveforms can be saved to a thumb drive via the USB host port on the front of the unit, or via the standard usb interface and free software that comes with the Siglent SDS1102CML.
Rigol DS1102E is a 2 channel, 100 MHz digital oscilloscope that comes with 1 Mpnt of memory and up to 1 GS/s sampling rates. It provides 20 types of wave parameters for automatically measuring, which contains 10 Voltage and 10 Time parameters.

SiglentSDS1102CMLDS1102E
The key differences are listed here:


 Feature / Model SDS1102CML DS1102E
Bandwidth 100 MHz 100 MHz
Memory 1 MP 1 MP
Rise Time 3.5 ns 3.5 ns
Data Logging Yes Yes
Sampling Rate 1 GS/s 1 GS/s
Analog Channels 2 2
For the Full Details of the differences please see below:
(click the ? for explanations of specification terms)

ModelRigol DS1102E
Product100 MHZ DSO Oscilloscope 2 CH 1 GSa/s
Rating(104)
Price
In Stock

Oscilloscopes/Digital Oscilloscopes

Bandwidth100 MHz
Channels2
Sampling Rate1 GS/S
Memory1 MP [megapoints] (1024 kB)
Rise Time3.5 ns
Screen Size5.7 IN
Bits8

Test Equipment General Attributes

Unique Features1 GSa/s maximum real-time sample rate, 25 GSa/s maximum equivalent-time sample rate
1Mpts long Memory Depth
100 MHz, 50 MHz Bandwidths
Ultra compact design: 303mm x 154mm x 133mm (WxHxD)
64 k TFT color LCD, bright and vivid waveform display
Advanced trigger modes: Edge, Video, Pulse Width, Slope, Alternate
Adjustable bigger sensitivity: Effactively filter noise from bigger signal and avoid false trigger
20 automatic measurements
Warranty3 YEARS
Safety ApprovalCE
Interfaces I/O RS-232, USB Host, USB
