| Model | Fluke Test Equipment & Tools 115 | Fluke Test Equipment & Tools 1587 |
|---|
| Product | Fluke 115 True-RMS AC/DC Digital Multimeter | INSULATION MULTIMETER |
|---|
| Rating | (79) | (3) |
|---|
| Price | | |
|---|
| In Stock | | |
|---|
|
Multimeters |
| Style | Hand-Held | Hand-Held |
|---|
| Measures AC V | Yes | Yes |
|---|
| Measures DC V | Yes | Yes |
|---|
| Measures AC A | Yes | Yes |
|---|
| Measures DC A | Yes | Yes |
|---|
| True RMS | Yes | Yes |
|---|
| Maximum Voltage AC | 600 V | 1000 V |
|---|
| Resolution AC Volts | 0.1 mV Resolution AC Volts Range / Resolution
0.600 V / 0.0001 V ( .1 mv )
6.000 V / 0.001 V ( 1 mv )
60.00 V / 0.01 V ( 10 mv )
600.0 V / 0.1 V ( 100 mv ) | 0.1 V (100 mV) |
|---|
| Maximum Voltage DC | 600 V | 1000 V |
|---|
| Resolution DC Volts | 0.1 mV Resolution DC Volts Range / Resolution
0.600 V / 0.0001 V ( .1 mv )
6.000 V / 0.001 V ( 1 mv )
60.00 V / 0.01 V ( 10 mv )
600.0 V / 0.1 V ( 100 mv ) | 0.001 V (1 mV) |
|---|
| Maximum Current AC | 10.0 A | 400 mA (0.4 A) |
|---|
| Minimum Current AC | 0.001 A (1 mA) | 1 mA |
|---|
| Resolution AC Current | 0.001 A (1 mA) | 0.01 mA |
|---|
| Maximum Current DC | 10.00 A | 400 mA (0.4 A) |
|---|
| Minimum Current DC | 0.001 A (1 mA) | 1 mA |
|---|
| Resolution DC Current | 0.001 A (1 mA) | 0.01 mA |
|---|
| Basic Accuracy V DC | 2% Basic Accuracy V DC 2% +3 counts | ±(0.09%+2) |
|---|
| # Digit Display | 3.5 # Digit Display Digital: 6,000 counts, updates 4 per second
Bar graph: 33 segments, updates 32 per second | 3.75 |
|---|
| Counts | 6000 . | 6000 . |
|---|
| Backlight | Yes | Yes |
|---|
| Manual/Autoranging | Both | Both |
|---|
| Decibels | No | No |
|---|
| Resistance | Yes | Yes |
|---|
| Frequency | Yes | Yes |
|---|
| Capacitance | Yes | Yes |
|---|
| Temperature | No | Yes |
|---|
| Diode Testing | Yes | Yes |
|---|
| CAT Rating | III CAT Rating 6 kV peak per IEC 61010-1 600 V CAT III, Pollution Degree 2 | IV |
|---|
| CAT Voltage | 600 V | 1,000 V, 600 V CAT Voltage CAT III 1000 V and CAT IV 600 V
|
|---|
| Intrinsically Safe | No | No |
|---|
| Peak Hold | No | Yes |
|---|
| Overload Protector | Yes Overload Protector 6 kV peak per IEC 61010-1 600 V CAT III, Pollution Degree 2 | Yes |
|---|
| Kelvin 4-Wire Measurement Capability | No | No |
|---|
| Wireless Display | No | No |
|---|
| Data Hold | Yes | Yes |
|---|
| Low-Pass Filter | No | Yes |
|---|
Micro / Milli / Meg Ohmmeters/Megohmmeter / Insulation Resistance Testers |
| IR Test Voltage | | 1,000 V, 100 V, 250 V, 50 V, 500 V |
|---|
| Maximum Insulation Resistance | | 2 G Ohms |
|---|
| Type | | Battery |
|---|
| Minimum Insulation Resistance | | 0.01 M Ohms (0.00001 G Ohms) |
|---|
| Variable Incremental Voltage | | No |
|---|
| Display (Megohmmeter) | | Digital |
|---|
| Continuity Test | | Yes |
|---|
| Live Circuit Voltage Detection | | Yes Live Circuit Voltage Detection Live circuit detection prevents insulation test if voltage > 30 V is detected for added user protection |
|---|
| Power Supply | | Battery |
|---|
| Timer | | No |
|---|
Test Equipment General Attributes |
| Unique Features | •Large white LED backlight to work in poorly lit areas
•Frequency and capacitance
•10A ac/dc current measurement (20 A overload for 30-seconds max)
•Min/Max/Average to record signal fluctuations
| Insulation test voltages 50V, 100V, 250V, 500V, 1000V
Insulation test: 0.01 MΩ to 2.0 GΩ
Auto discharge of capacitive voltage
Insulation test smoothing reading
Frequency
Capacitance
Diode test
Temperature
Min/Max
Low pass filter (for work on VSD's)
AC/DC Voltage
DC millivolts
AC/DC milliamps |
|---|
| Warranty | 3 YEARS | 3 YEARS |
|---|
| Safety Approval | CSA, UL Safety Approval ANSI/ISA 82.02.01 (61010-1) 2004, CAN/CSA C22.2 No 61010-1-04, UL 6101B (2003) and IEC/EN
61010-1 2nd Edition for measurement Category III, 600 V, Pollution Degree 2, EMC EN61326-1 | CSA |
|---|
| Interfaces I/O | Analog Output, Analog Input | N/A |
|---|
| IP Rating | IP42 | IP40 |
|---|
| Product Weight | 1.34 LBS | 4.72 LBS |
|---|
| Product Height | 1.82 IN | 7.99 IN |
|---|
| Product Length | 6.57 IN | 3.97 IN |
|---|
| Product Width | 3.31 IN | 7.96 IN |
|---|
| Shipping Weight | | 5.19 LBS |
|---|
| Data Logging | No | No |
|---|
| HTS/Schedule B Number | N/A | 9030.31.0000 |
|---|
| ECCN Number | 3A992 | 3A992 |
|---|
| Calibration Included | Factory Calibration Calibration Included Factory Calibrated without certification. | None |
|---|
| Battery Type | 9v | AA Battery Type 4x AA Batteries |
|---|
| Power Supply Voltage | Battery Powered | Battery Powered |
|---|
| Country of Origin | Singapore | United States |
|---|
| Shipping Height | | 7.99 IN |
|---|
| UPC | 095969324182 | 095969262958 |
|---|
| Shipping Length | | 3.97 IN |
|---|
| Shipping Width | | 7.96 IN |
|---|
