| Model | Fluke Ti95 | FLIR E4 WiFi |
|---|
| Product | THERMAL IMAGER, W/FLUKE CONNECT | FLIR E4 IR Camera w/MSX 80 x 60 Resolution/9Hz with WiFi |
|---|
| Rating | (0) | (51) |
|---|
| Price | | |
|---|
| In Stock | | |
|---|
Thermal Imagers/Building and Industrial Thermal Imagers |
| Detector Size | 80 x 80 Sensor | 80 x 60 Sensor Detector Size Image Example:
|
| Thermal Sensitivity | 100 mK (NETD) Thermal Sensitivity ≤ 0.10 °C at 30 °C target temp (100 mK) | 150 mK (NETD) Thermal Sensitivity <0.15°C |
| Temperature Range Max | 250 C (482 F) Temperature Range Max -20 °C to +250 °C (-4 °F to +482 °F) | 482 F |
| Temperature Range Min | -20 C (-4 F) | -4 F |
| Image Frequency | 9 Hz | 9 Hz |
| Field of View | 26x26 Degrees Field of View 26 °H x 26 °V | 45x34 Degrees |
| Screen Size | 3.5 IN Screen Size Portrait Format | 3.0 IN |
| IR/Overlay Fusion Image | No IR/Overlay Fusion Image Available with included SmartView Software | Yes IR/Overlay Fusion Image MSX Image Enhancement is a FLIR exclusive feature. It augments the Infrared image with visual details like numbers, labels and other structural features. |
| Video Output | No | No |
| Focus | Fixed | Fixed |
| Laser Spot | No | No |
| Picture in Picture | Yes | No |
| Video Recording | No | No |
| Moveable Spots | No Moveable Spots In SmartView® Software only | No Moveable Spots In FLIR Tools Software only |
| Touch Screen Display | No | No |
| Minimum Focus Distance | 48 IN (1.22 M) | 1.6 Ft (0.488 M) |
| Accuracy | ± 2 °C or 2 % (at 25 °C nominal, whichever is greater) | ±2% or 2°C |
| Battery operating time Continuous | 4 HR | 4 HR |
| Camera Light | No | No |
| IR Digital Zoom | No | No |
| Voice Annotation | No | No |
| Intrinsically Safe | | No |
Test Equipment General Attributes |
| Unique Features | Fluke Connect™ wireless—save and share measurements from the field with your team anytime, from anywhere | Image modes: Thermal MSX, thermal, picture-in-picture, thermal blending, digital camera Color palettes: Iron, Rainbow, Black & White WIFI Connectivity Includes FLIR TOOLS software |
| Warranty | 2 YEARS | 1 YEARS |
| Warranty Details | | 10-Year Detector Protection 5-Year Battery 2-Year Parts & Labor (when camera is registered within 60 Days) |
| Safety Approval | CSA, UL Safety Approval CSA (US and CAN): C22.2 No. 61010-1-04, UL: UL STD 61010-1 (2nd Edition), ISA: 82.02.01 | CE, CSA, RoHS, UL |
| Interfaces I/O | Wifi, USB Interfaces I/O USB Mini connector for downloading direct to PC Fluke Connect™ wireless—save and share measurements from the field with your team anytime, from anywhere | Wifi, USB |
| Storage | SD Card Storage Removable 8GB WiFi SD Card & 4GB SD Card included | Internal Memory Storage Internal memory holds 500 sets of images |
| IP Rating | IP54 | IP54 |
| Product Weight | 1.6 LBS | 1.27 LBS |
| Product Height | 11.2 IN | 7.00 IN |
| Product Length | 3.4 IN | 13.00 IN |
| Product Width | 5.2 IN | 16.00 IN |
| Shipping Weight | 7.11 LBS | |
| Data Logging | No | Yes Data Logging Internal memory holds 500 sets of images |
| HTS/Schedule B Number | | 9027.50.4020 |
| ECCN Number | | 6A993 |
| Calibration Included | Factory Calibration | None |
| Battery Type | Li-ion | Li-ion Battery Type Removable Battery
Quick-release, tool-type Li-ion battery is easy to remove, recharge and snap back in. Charge in-camera or with the optional charging station to keep you up and running all day. |
| Power Supply Voltage | 120V/220V Universal, Battery Powered | 120V/220V Universal Power Supply Voltage Adapter is 120V/220V Universal. Recharges Battery. |
| Country of Origin | United States | Estonia |
| Shipping Height | 8.00 IN | |
| Shipping Length | 12.50 IN | |
| Shipping Width | 8.00 IN | |
