• Internal capacity: 90L
• Power source: 220V 5.5A (no plug, round terminal)
• High precision controller allows high-performance temperature control and display of CO₂ and power discharge
• Heat tightness and insulation design of the chamber achieve an energy-saving rate of about 40% at constant temperature compared to previous models

High-performance environment-friendly eco-oven that reduces power consumption significantly.

Operation and functions

• Maximum temperature reaching time reduced by 15 minutes (no-load) compared to previous models
• Program operation with a maximum of 99 steps, 99 patterns repeatable
• Standard equipped with various support functions such as calibration offset, power failure recovery mode, save and access of user setting information, as well as other operation modes
• Data acquisition from internal test device possible because of cable holes
• Easy system upgrade with various option settings

Safety features

• Standard equipped with various self-diagnostic functions such as independent overheat prevention device, overcurrent circuit breaker, and key lock function

*¹ Temperature Accuracy / Rise time Standard: Testing Machinery Association of Japan. Temperature Fluctuation/Gradient Standard: Japanese Industrial Standard. Performance data above is based on 115V or 220V AC supplied power, 23°C±5°C (room temperature), 65%RH ±20% humidity, maximum air speed (FAN setting 10), damper closed, and no process load.

*² Protrusions excluded
