| YSI ProDSS General Specifications |
| Size |
Instrument: 8.3 cm width x 21.6 cm length x 5.6 cm depth (3.27 in x 8.5 in x 2.21 in)
4 port bulkhead with sensor guard, no depth: 42.82 cm (16.86 in) length and 4.75 cm (1.87 in) outer diameter
4 port bulkhead with sensor guard, with depth: 45.36 cm (17.86 in) length and 4.75 cm (1.87 in) outer diameter
ODO/CT assembly with sensor guard: 26.14 cm (10.29 in) length and 2.46 cm (0.97 in) outer diameter |
| Handheld weight with batteries |
567 grams (1.25 lbs) |
| Power |
Rechargeable lithium-ion battery pack provides ~48 hours with the handheld only and ~20 hours with the handheld, 4 port cable and 4
smart sensors; battery recharge time is ~9 hours with the AC power adapter
The instrument can also be powered via AC or external power pack through the USB port |
| Instrument operating temperature |
0 to 50 °C (32 to 122 °F) |
| Display |
Color, LCD graphic display; 3.9 cm width x 6.5 cm height |
| USB port |
Built-in micro USB On-The-Go port for PC connection, recharging/powering the ProDSS and connecting directly to a USB stick |
| Cables |
ProDSS 4 port, ProDSS ODO/CT, and ProODO field cables available in 1, 4, 10, 20, 30, 40, 50, 60, 70, 80, 90, and 100-meters; ProDSS 4 port cables feature an optional depth sensor; ProOBOD cable assemblies are also compatible |
| Sensor ports |
4 port cables feature universal sensor ports that can accept any ProDSS sensor; other compatible cables feature integral sensors |
| Warranty |
3-year instrument; 2-year bulkhead, cable assembly, sensors, and extended warranty ODO sensor cap (627180); 1-year pH and pH/ORP sensor modules, ODO sensor caps, and Li-ion battery pack; 6-months ammonium, nitrate, and chloride sensor modules |
| Memory |
> 100,000 data sets |
| Logging modes |
Single point or continuous with autostable feature |
| GLP compliance |
Yes; 400 detailed GLP records can be stored and are available to view, download, and print. |
| Languages |
English, Spanish, German, French, Italian, Norwegian, Portuguese, Japanese, Chinese (Simplified & Traditional), Korean, Thai |
| Certifications |
CEC, CE; RoHS; IP-67; WEEE; FCC; UN Part III, Section 38.3, Test methods for lithium-ion batteries (Class 9) |
| GPS |
Optional internal GPS; coordinates are stored with measurement data and site lists |
| Sites and data ID |
100 user-defined sites and 100 user-defined data ID tags; site pictures can be sent to the handheld via KorDSS |
