Vitrek V77 - AC/DC/IR Scanning Hipot Tester with Ground Bond Test

Name: Vitrek V77 - AC/DC/IR Scanning Hipot Tester with Ground Bond Test
Brand: Vitrek
SKU: VitrekV77
Price: 4157.89 USD
Availability: InStock

0 reviews | Model: Vitrek V77

Compare

AC/DC/IR Scanning Hipot Tester with Ground Bond Test, 2500VAC/2750VDC/IR/Continuity Electrical Safety tester

AC/DC/IR Scanning Hipot Tester with Ground Bond Test
2500VAC/2750VDC/IR/Continuity Electrical Safety tester
Built-in switching for up to 8 channels of HV, 8 channels of return, and 8 channels of continuity
5KV AC/DC Hipot, 20mA max source current
Ground Bond 1-30A RMS (42 A peak), 100µΩ Resolution
100 nano-Amp Leakage Current Resolution
Low Cost of Ownership – 2 Year Calibration Interval
USB 2.0, Serial/RS232, Digital I/O Interfaces are Standard
Continuously Variable Insulation Resistance 20-5000V, 450GΩ Max
150µS Safety Shutdown

View Product Details

List Price: $4,424.00

In Stock:

View Payment Options

Recommended for you

Vitrek V77

AC/DC/IR Scanning Hipot Tester with Ground Bond Test
2500VAC/2750VDC/IR/Continuity Electrical Safety tester
Built-in switching for up to 8 channels of HV, 8 channels of return, and 8 channels of continuity
5KV AC/DC Hipot, 20mA max source current
Ground Bond 1-30A RMS (42 A peak), 100µΩ Resolution

AC/DC/IR Scanning Hipot Tester with Ground Bond Test

AC/DC/IR Scanning Hipot Tester with Ground Bond Test. 2500VAC/2750VDC/IR/Continuity Electrical Safety tester with built-in switching for up to 8 channels of HV, 8 channels of return, and 8 channels of continuity. Ground Bond available on front panel only. Comes with: TL-209, Power Cord, Operating Manual, QTPro-7 45 Day Free Trial, NIST Traceable calibration certificate without data. ISO 17025 accredited calibration certificate with data and uncertainties available with purchase at reduced price with part number: ISO-CALN-V7X.
