Vitrek V51 - AC / DC Electrical Safety Tester

Name: Vitrek V51 - AC / DC Electrical Safety Tester
Brand: Vitrek
SKU: VitrekV51
Availability: InStock

0 reviews | Model: Vitrek V51

Compare

AC/DC Electrical Safety Tester

AC, DC Withstanding Voltage Test & Insulation Resistance Test
Arc Detect and Continuity Check as Additional Features
Thoughtful safety design to give a safe test environment
Output voltage and current limit could be set without HV output
6 sets memory for front panel setting and test sequence store/recall
Linear amplifier with feedback control to provide highly regulated power
9 pin PLC control for start, stop, and test result output
100VA Test Capacity

View Product Details

In Stock:

View Payment Options

Recommended for you

Vitrek V51

AC, DC Withstanding Voltage Test & Insulation Resistance Test
Arc Detect and Continuity Check as Additional Features
Thoughtful safety design to give a safe test environment
Output voltage and current limit could be set without HV output
6 sets memory for front panel setting and test sequence store/recall

AC / DC Electrical Safety Tester

QT-50 Bundled V50 Quicktest Software with PC interface adaptor and cable
PC Interface Adaptor & Cable
TL-115/50 Nema 5-15 Test Adapter
TL-1050 High Voltage Probe Lead Set
TL-2050 Alligator Test Lead Set
TL-IEC50 IEC Power Socket Test Lead
OM-50 Additional Operators Manual

QuickTest Software

Bundled test automation software with PC interface adapter and cable. Easy to load Graphical test sequence development and operating environment. Provides time/date, operator, test parameters, and test results for review, printout or export to database program.

QT-50:

Model	AC	DC	IR
V50	Y
V51	Y	Y
V52	Y		Y
V53	Y	Y	Y

SPECIFICATIONS
AC HI-POT	Voltage Range	0.100kV ~ 5.000kV
	Voltage Step	5V/step
	Voltage Regulation	1% of reading + 5 counts
	Voltage Accuracy	1% of reading + 5 counts
	Max Current	20mA @5kV
	Current Limit	0.10 ~ 20mA, 0.01mA/step
	Current Accuracy	1% of reading + 5 counts

DC HI-POT (V51 / V53 ONLY)	Voltage Range	0.100kV ~ 6.000kV
	Voltage Step	5V/step
	Voltage Regulation	1% of reading + 5 counts
	Voltage Accuracy	1% of reading + 5 counts
	Max Current	7.5mA @5kV
	Current Limit	0.10 ~ 7.5mA, 0.01mA/step
	Current Accuracy	1% of reading + 5 counts

Insulation Resistance (V52 / V53 ONLY)	DC Voltage	500V/1000V
	Resistance Range	1 ~ 9999M
	Resistance Accuracy	1 ~ 500M : 5% of reading 501 ~ 2000M : 10% of reading

Continuity Check	Test Current	0.1A
	Current Accuracy	10%
	Detect Level	1Ω
	Detect Accuracy	0.1Ω

ARC Detect	Detect Current	10 level (2 ~ 20mA)

Storage	Groups	6
Storage	Steps per Group	6

Interface	Type of terminal	9-pin D-sub connector
	Output Breakdown Voltage	+350V
	Continuous Load Current	+100mA

Power Source	AC100V,120V,220V,230V+10% 50/60Hz

Accessories	Power cord x 1, Instruction manual x 1, GHT-105 x 1

Dimensions & Weight	330(W) x 149(H) x 446(D) mm, Approx. 12kg
