| IR resolution |
320 × 240 pixels |
| Thermal sensitivity/NETD |
< 0.05°C @ +30°C (+86°F) / 50 mK |
| Field of view (FOV) |
FLIR A310f 15°: 15° × 11.25°
FLIR A310f 25°: 25° × 18.8°
FLIR A310f 45°: 45° × 33.8°
FLIR A310f 6°: 6° × 4.5°
FLIR A310f 90°: 90° × 73° |
| Minimum focus distance |
FLIR A310f 15°: 1.2 m (3.93 ft.)
FLIR A310f 25°: 0.4 m (1.31 ft.)
FLIR A310f 45°: 0.20 m (0.66 ft.)
FLIR A310f 6°: 6° × 4.5°
FLIR A310f 90°: 20 mm (0.79 in.) |
| Focal length |
FLIR A310f 15°: 30.38 mm (1.2 in.)
FLIR A310f 25°: 18 mm (0.7 in.)
FLIR A310f 45°: 9.66 mm (0.38 in.)
FLIR A310f 6°: 76 mm (3.0 in.)
FLIR A310f 90°: 4 mm (0.157 in.) |
| Spatial resolution (IFOV) |
FLIR A310f 15°: 0.82 mrad
FLIR A310f 25°: 1.36 mrad
FLIR A310f 45°: 2.45 mrad
FLIR A310f 6°: 0.33 mrad
FLIR A310f 90°: 6.3 mrad |
| Lens identification |
Automatic |
| F-number |
1.3 |
| Imaging and optical data |
| Image frequency |
30 Hz |
| Focus |
Automatic or manual (built in motor) |
| Zoom |
1–8× continuous, digital,
interpolating zooming on images |
| Detector data |
| Detector type |
Focal Plane Array (FPA), uncooled microbolometer |
| Spectral range |
7.5–13 μm |
| Detector pitch |
25 μm |
| Detector time constant |
Typical 12 ms |
| Measurement |
| Object temperature range |
–20 to +120°C (–4 to +248°F)
0 to +350°C (+32 to +662°F) |
| Accuracy |
±4°C (±7.2°F) or ±4% of reading |
| Measurement analysis |
| Spotmeter |
10 |
| Area |
10 boxes with max./min./average/position |
| Isotherm |
1 with above/below/interval |
| Measurement option |
Measurement Mask / Filter Schedule response: File
sending (ftp), email (SMTP) |
| Difference temperature |
Delta temperature between measurement
functions or reference temperature |
| Reference temperature |
Manually set or captured from
any measurement function |
Atmospheric transmission
correction |
Automatic, based on inputs for distance,
atmospheric temperature and relative humidity |
| Optics transmission correction |
Automatic, based on signals
from internal sensors |
| Emissivity correction |
Variable from 0.01 to 1.0 |
Reflected apparent
temperature correction |
Automatic, based on input of reflected temperature |
External optics/
windows correction |
Automatic, based on input of optics/window
transmission and temperature |
| Measurement corrections |
Global and individual object parameters |
| Alarm |
| Alarm functions |
6 automatic alarms on any selected measurement
function, Digital In, Camera temperature, timer |
| Alarm output |
Digital Out, log, store image, file sending (ftp), email
(SMTP), notification |
| Ethernet |
| Ethernet |
Control, result and image |
| Ethernet, type |
100 Mbps |
| Ethernet, standard |
IEEE 802.3 |
| Ethernet, connector type |
RJ-45 |
| Ethernet, communication |
TCP/IP socket-based FLIR proprietary |
| Ethernet, video streaming |
MPEG-4, ISO/IEC 14496-1 MPEG-4 ASP@L5 |
| Ethernet, image streaming |
16-bit 320 × 240 pixels @ 7-8 Hz- Radiometric |
| Ethernet, power |
Power over Ethernet, PoE IEEE 802.3af class 0 |
| Ethernet, protocols |
Ethernet/IP, Modbus TCP, TCP, UDP, SNTP, RTSP,
RTP, HTTP, ICMP, IGMP, ftp, SMTP, SMB (CIFS),
DHCP, MDNS (Bonjour), uPnP |
| Set-up |
| Color palettes |
Color palettes (BW, BW inv, Iron, Rain) |
| Set-up commands |
Date/time, Temperature°C/°F |
| Storage of images |
| Storage media |
Built-in memory for image storage |
| File formats |
Standard JPEG, 16-bit
measurement data included |
| Digital input/output |
| Digital input, purpose |
Image tag (start/stop/general), Input ext.
device (programmatically read) |
| Digital input |
2 opto-isolated, 10–30 VDC |
| Digital output, purpose |
As function of ALARM, Output to ext. device
(programmatically set) |
| Digital output |
2 opto-isolated, 10–30 VDC, max 100 mA |
| Digital I/O, isolation voltage |
500 VRMS |
| Digital I/O, supply voltage |
12/24 VDC, max 200 mA |
| Digital I/O, connector type |
6-pole jackable screw terminal |
| Power system |
| External power operation |
The camera operates on 12/24 VDC, 9 W max.
(allowed range: 10-30 VDC) and heaters on 24 VDC, |
| 25 W max. In total |
34 W. |
| External power, connector type |
2-pole jackable screw terminal |
| Voltage Allowed |
range 10–30 VDC |
| Environmental data |
| Operating temperature range |
–25°C to +50°C (–13°F to +122°F) |
| Storage temperature range |
–40°C to +70°C (–40°F to +158°F) |
| Humidity (operating and storage) |
IEC 60068-2-30/24 h 95% relative humidity +25°C
to +40°C (+77°F to +104°F) |
| EMC |
• EN 61000-6-2 (Immunity)
• EN 61000-6-3 (Emission)
• FCC 47 CFR Part 15 Class B (Emission) |
| Encapsulation |
IP 66 (IEC 60529) |
| Bump |
5 g, 11 ms (IEC 60068-2-27) |
| Vibration |
2 g (IEC 60068-2-6) |
| Physical data |
| Weight |
5 kg (11.0 lb.) |
| Size (L × W × H) |
460 × 140 × 159 mm (18.1 × 5.5 × 6.3 in.) |
| Base mounting |
TBA |
| Housing material |
Aluminum |
| System features |
| External power operation (heater) |
24 VDC, 25 W max. |
External power,
connector type (heater) |
2-pole jackable screw terminal |
| Voltage (heater) |
Allowed range 21-30 VDC |
| Automatic heaters |
Clears window from ice |
