| Imaging and optical data |
| IR resolution |
320 × 240 pixels |
| tdermal sensitivity/NETD |
<15 mK @ +30°C (+86°F) |
| Field of view (FOV) |
24° × 18° witd 23 mm lens; 14.5 x10.8 witd 38 mm lens |
| Minimum focus distance |
0.3 m (1.0 ft.) for 23 mm lens; 0.5 m (1.64 ft) for 38 mm lens |
| F-number |
1,5 |
| Focus |
Automatic using FLIR SDK, or manual |
| Zoom |
1–8× continuous, digital zoom |
| Digital image enhancement |
Noise reduction filter, High Sensitivity Mode (HSM) |
| Detector data |
| Detector type |
Focal Plane Array (FPA), cooled InSb |
| Spectral range |
3.2–3.4 μm |
| Image presentation |
| Automatic image adjustment |
Continuous/manual; linear or histogram based |
| Manual image adjustment Level/span |
Level/span |
| Image presentation modes |
| Image modes |
IR-image, High Sensitivity Mode (HSM) |
| Electronics and data rate |
| Full frame rate |
60 Hz |
| Temperature ranges |
| Temperature range |
–20°C to +350°C (–4°F to +662°F) |
| Video streaming |
| Non-radiometric IR-video streaming |
RTP/MPEG4 |
| USB |
| USB |
Control and image |
| USB, standard |
2.0 High Speed |
| USB, connector type |
USB micro |
| USB, communication |
TCP/IP socket-based, Microsoft RNDIS and/or USB video class |
| USB, video streaming |
640 × 480 pixels at 30 Hz |
| USB, image streaming |
16-bit 320 × 240 at 30 Hz |
| USB, protocols |
TCP, UDP, RTSP, RTP, HTTP, ICMP, IGMP, ftp,DHCP |
| Etdernet |
| Etdernet |
Control, result and image |
| Etdernet, type |
100 Mbps |
| Etdernet, standard |
IEEE 802.3 |
| Etdernet, connector type |
RJ-45 |
| Etdernet, communication |
TCP/IP socket-based FLIR proprietary |
| Etdernet, video streaming |
640 × 480 pixels at up to 15 Hz, MPEG-4, ISO/IEC 14496-1 MPEG-4 ASP@L5 |
| Etdernet, image streaming |
16-bit 320 × 240 pixels at up to 10 Hz |
| Etdernet, protocols |
TCP, UDP, RTSP, RTP, HTTP, ICMP, IGMP, ftp,DHCP, MDNS (Bonjour), SMB/CIFS |
| Data communication interfaces |
| Interfaces |
Etdernet / HDMI |
| Composite video |
| Video out |
Digital Video Output (image) |
| Imaging and optical data (visual camera) |
| Field of view (FOV) / Focal lenghts |
NA |
| F-number |
NA |
| Focus |
NA |
| Optical Zoom |
NA |
| Electronic Zoom |
NA |
| Detector data (visual camera) |
| Focal Plane Array (FPA) / Effective pixels |
NA |
| Technical specification (pan & tilt) |
| Azimutd Range Az velocity |
NA |
| Elevation Range El velocity |
NA |
| Programmable presets |
NA |
| Automatic heaters |
NA |
| Power system |
| DC operation |
10–28 V DC, polarity protected |
| Start-up time |
Typically 7 min. @ 25°C (+77°F) |
| Environmental data |
| Operating temperature range |
–20°C to +50°C (–4°F to +122°F) |
| Storage temperature range |
–30°C to +60°C (–22°F to +140°F) |
