| Parameter |
Resolution |
Accuracy |
Range |
| Measurement |
| Flue Measurement with probe |
1.0°F/C |
±2.0°F/C, ±0.3% of rdg |
32° - 1112°F
(0° - 600°C) |
| Inlet Temperature |
0.1°F/C |
±1.0°F/C, ±0.3% of rdg |
32° - 122°F
(0° - 50°C) |
| Pressure |
0.1 mbar |
±2% of full scale |
+150 mbar to -150 mbar |
| Gas Measurement*1 |
| Oxygen(O2) |
0.1% |
±0.2% |
0 - 21% |
Carbon Monoxide (CO)
(standard: H compensated)
(optional) |
1 ppm |
±20 ppm <400 ppm
±5% >5000 ppm
±10%<5000 ppm |
0 - 10,000 ppm |
Carbon Monoxide (CO)
(High range)(optional) |
0.01% |
±5% reading from 0.1% to 10% |
0 ~ 10% |
Nitric Oxide (NO)
(standard)(optional) |
1 ppm |
±5 ppm <100 ppm
±5%>100 ppm |
0 - 5000 ppm |
Nitric Oxide (NO)
(Low range)(optional) |
1 ppm |
±2 ppm <30 ppm
±5 ppm <30 ppm |
0 ~ 100 ppm |
Nitrogen Dioxide
(optional) |
1 ppm |
±5 ppm<100 ppm
±10 ppm<500 ppm
±5%>500 ppm |
0 ~ 1000 ppm |
Sulphur Dioxide
(optional) |
1 ppm |
±5 ppm<100 ppm
±5%>100 ppm |
0 ~ 5000 ppm |
| Calculations |
| Carbon Dioxide*2 |
0.1% |
±0.3% reading |
0 ~ 99.9% |
| Losses |
0.1% |
±1.0% reading |
0 ~ 99.9% |
| Efficiency |
0.1% |
±1.0% reading |
0 ~ 99.9% |
| Excess Air |
0.1% |
±0.2% |
0 ~ 2885.0% |
| Temp (Nett) |
1.0°C/F |
±2°C ±0.3% reading |
32 ~ 1112°F
(0 ~ 600°C) |
| CO/CO2 Ratio |
0.0001 |
±0.0001 |
0 ~ 0.9999 |
| Poison Index |
0.01% |
±0.01 |
0 ~ 99.99 |
| Parameter |
Description |
| Preprogrammed fuels |
Natural Gas, Town Gas, Gascor, Light Oil, Heavy Oil, Propane, Butane, Anthrocite, Coke, Coal, Kinsale Gas |
| Dimensions: |
|
| • Weight |
1 Kg |
| • Handset |
220 x 55 x 120 mm |
| • Probe |
(L) 420 x (Dia) 8mm with stainless steel shaft, K-type thermocouple and 3m hose |
| Ambient operating range |
0°C to 45°C/10% to 90% RH non condensing |
Power supply
(Battery charger) |
Input: 110V AC / 220V AC nominal
Output: 12V AC off load |
| Battery life |
>6 hours from full charge |
