UEi K9206C2 - Industrial Combustion Analyzer with Wireless Handset

0 reviews | UPC: 053533507300 | Model: UEi K9206C2

UEi K9206 Industrial Combustion Analyzer with Wireless Handset

Compare

BASE UNIT PLUS NO1/NO2

Preconfigured sensor combinations: O2, CO, Pressure, Temperature. NO and NO2 sensors
Industrial emissions grade analyzer
Optional heated sample line
Optional sample conditioner
Wireless handset to base or PC
On board plain paper printer
Heated sensor manifold to prevent condensation
Automatic fresh air purge
Rugged case
1-Year limited warranty

View Product Details

List Price: $8,015.95

In Stock:

View Payment Options

Recommended for you

UEi K9206C2 - Industrial Combustion Analyzer with Wireless Handset

Preconfigured sensor combinations: O2, CO, Pressure, Temperature. NO and NO2 sensors
Industrial emissions grade analyzer
Optional heated sample line
Optional sample conditioner
Wireless handset to base or PC

The UEi K9206C2 is a versatile heavy-duty industrial combustion analyzer. Users can select from pre-defined sensor combinations (O2, CO, Pressure, Temperature. NO and NO2 sensors) or customize an order by fitting any combination of up to seven additional sensors. The K9206 is built to test combustion systems over 10,000 MBTU/h with high concentration gas levels for extended duration.

Applications include:

Installation, commissioning and service of industrial/commercial oil, gas or biomass appliances
Combustion performance checks
Combustion efficiency checks
Flue draft

The K9206 is available in several configurations. The chart below provides an overview of each.

K9206 Sensor Options
UEI Part Number	K9206	K9206C2	K9206C3	K9206C4	K9206C5	K9206C6	K9206C7
O2 Sensor	X	X	X	X	X	X	X
CO Sensor	X	X	X	X	X	X	X
Pressure	X	X	X	X	X	X	X
Temperature	X	X	X	X	X	X	X
NO		X	X	X		X	X
NO2		X		X			X
SO2			X	X			X
HC/CO%/CO2					X	X	X

Gas Measurement	Range	Resolution	Accuracy	Overrange
Pressure	0 to 150 mBar	0.01 mBar	±0.5% F.S
CO2	0 to Fuel Value	0.10%	±0.3%
Efficiency	0 to 100%	0.1%	±1%
O2	0 to 25%	0.01%	-0.1% + 0.2%
CO	2000 ppm	1 ppm	<100 ppm ±5 ppm >100 ppm <1000 ppm ±5% rdg >2000 ppm <4000 ppm ±10% rdg	4000 ppm
NO (high range)	1000 ppm	1 ppm	<100 ppm ±5 ppm >100 ppm <1000 ppm ±5% rdg >2000 ppm <5000 ppm ±10% rdg	5000 ppm
NO (low range)	100 ppm	1 ppm	<100 ppm ±5 ppm >100 ppm <300 ppm	300 ppm
NO2	100 ppm	1 ppm	<100 ppm ±5 ppm >100 ppm <500 ppm ±10% rdg	1000 ppm
SO2 (low range)	100 ppm	1 ppm	<100 ppm ±5 ppm >100 ppm <500 ppm ±10% rdg	500 ppm
SO2 (high range)	2000 ppm	1 ppm	<100 ppm ±5 ppm >100 ppm <2000 ppm ±5% rdg >2000 pm <5000 ppm ±10% rdg	5000 ppm
H2S	200 ppm	1 ppm	<100 ppm ±5 ppm >100 ppm <200 ppm ±5% rdg >2000 pm <300 ppm ±10% rdg	300 ppm
Flue temperature	32˚ to 2140˚F (0 to 1100˚C)	0.1˚ F/C	1.8˚F (1.0˚C) ±0.3% rdg
Inlet temperature	0˚ to 999˚F (0˚ to 600˚C)	0.1˚ F/C	1.8˚F (1.0˚C) ±0.3% rdg

Languages	3
Auto purge	●
Main purge time	2 to 60 min.
Main purge interval time	10 to 120 min
Auto zero	●
Auto pump flow	●
Auto set time	●
Fuel types	20
Gas units	5
Temperature	˚F/˚C
Pressure units	6
