| Detector type | FPA 320 x 240 pixels, a.Si |
| Thermal sensitivity (NETD) | <60 mK at 86°F (30°C) |
| Field of view / min. focus distance | 32° x 23° / 7.8" (standard lens) |
| Geometric resolution (IFOV) | 1.7 mrad |
| Image refresh rate | 33 Hz |
| Focus | Manual and motor focus |
| Spectral range | 8 to 14 µm |
| Optical field / min. focus distance | 33° x 25° / 15.7" |
| Image size | 640 x 480 pixels |
| Image display | 3.5" LCD with 320 x 240 pixels |
| Display options | Only IR / only digital image / IR and digital image |
| Video output | USB 2.0 |
| Color palettes | 9 options (ironbow, rainbow, cold/hot, blue/red, greyscale, inverted grey, sepia, testo, iron) |
| Temperature range | -4°F to 212°F (-20°C to +100°C)
+32°F to +662°F (0°C to 350°C), switchable |
| High temperature (optional) | +662°F to +1022°F (350°C to +550°C) |
| Accuracy | ± 2°C, ± 2% of rdg, (-4°F to +662°F)
± 3°C, ± 3% of rdg, (+662°F to +1022°F) |
| Minimum diameter measurement point | 0.2’’ at 3 ft. |
| Setting emissivity | 0.01 to 1 |
| File format | .bmt; export options in .bmp, .jpg, .png, .csv, .xls |
| Data storage device | 2 GB SD card (approx. 1000 images) |
| Battery type | Li-ion battery |
| Operating time | 4 hours |
| Operating temperature range | 5°F to +104°F |
| Storage temperature range | -22°F to +140°F |
| Protection class of housing | IP 54 |
| Weight | Approx. 2 lbs |
| Dimensions | 6" x 4.2" x 10.3" |
| Tripod mounting | Yes with adapter |
| Housing | ABS |
| System requirements | Windows XP (Service Pack 2) Windows Vista, Windows 7, USB 2.0 interface |
| Warranty | 2 years |
