Testo 0635 9572 - 16mm Vane Probe with Temperature Sensor (Includes Wired Handle)

Name: Testo 0635 9572 - 16mm Vane Probe with Temperature Sensor (Includes Wired Handle)
Brand: Testo
SKU: Testo0635 9572
Price: 1008.10 USD
Availability: InStock

0 reviews | Catalog: 0635 9572 | UPC: 4029547018909 | Model: Testo 0635 9572

Images (5) | Videos (1)

Compare

Vane probe ( Diameter 16 mm) incl. temperature sensor, fixed cable

16mm Vane Probe with Temperature Sensor
Includes wired handle
Used to measure air velocity, volume flow and air temperature
Accurate measurement results from +0.6 to +50 m/s
Probe with a practical button on the handle for storing individual readings, convenient measurement in any cross-section with scaled telescope (up to 1 m), optionally extendable to 2.0 m
Must be used along with a compatible Testo multifunction instrument

View Product Details

List Price: $1,186.00

Your Price: $1,008.10

Sign-in for GSA and EDU Pricing!

In Stock:

Free shipping over $99 - Code: FREESHIP
Please note, FREE SHIPPING is only available on items that can ship via standard ground shipping and is only valid within the Contiguous United States. Any items that must ship via freight or to any destination outside of the Contiguous United States will be excluded. - USE CODE FREESHIP at checkout

Valid on Web Price Only!
View Payment Options

Request Quote

Items in This Series



Product	Testo 0635 9572 Vane probe ( Diameter 16 mm) incl. temperature sensor, fixed cable	Testo 0635 9570 16 mm vane probe head incl. temperature probe	Testo 0635 9571 Vane probe ( Diameter 16 mm) with Bluetoot, incl. temperature sensor
Price
In Stock
Compare	Add to compare	Add to compare	Add to compare

Recommended for you

Testo 0635 9572 Accessories

Choose a Category

HVAC Accessories
Temperature Probes

for the Testo 0635 9572

Testo 0554 0990 Telescope extension (length 0.40 to 0.85 m) for testo 400 air flow probes

Catalog: 0554 0990

(0)

In Stock!

Add to Cart

Testo 0632 1270 CO probe head

Catalog: 0632 1270

(0)

In Stock!

Add to Cart

Testo 0632 1550 CO2 probe head incl. temperature and humidity sensor

Catalog: 0632 1550

(0)

In Stock!

Add to Cart

Testo 0635 1570 Hot wire probe head incl. temperature and humidity sensor

Catalog: 0635 1570

(0)

In Stock!

Add to Cart

Testo 0635 9370 High-precision 100 mm vane probe head incl. temperature probe

Catalog: 0635 9370

(0)

In Stock!

Add to Cart

Testo 0635 9430 100 mm vane probe head

Catalog: 0635 9430

(0)

In Stock!

Add to Cart

Testo 0635 9570 16 mm vane probe head incl. temperature probe

Catalog: 0635 9570

(0)

In Stock!

Add to Cart

Testo 0636 9730 Temperature-humidity probe head

Catalog: 0636 9730

(0)

In Stock!

Add to Cart

Testo 0636 9770 High-precision temperature-humidity probe head

Catalog: 0636 9770

(0)

In Stock!

Add to Cart

Testo 0635 9572 - 16mm Vane Probe with Temperature Sensor (Includes Wired Handle)

Includes wired handle
Used to measure air velocity, volume flow and air temperature
Must be used along with a compatible Testo multifunction instrument

The Testo 0635 9572 is a 16mm vane probe with a sensor for measuring temperature. The 0635 9572 includes a wired handle (not Bluetooth) for connection to your measuring device. Please note, this probe cannot be used on its own - it must be used with a Testo multifunction instrument.

This vane probe is designed to determine air velocity, volume flow and air temperature. The vane probe has a measuring range of +0.6 to +50 m/s and features maximum accuracy from 5 m/s.

Vane probe including temperature sensor

Use the fixed cable on the handle to connect the vane probe to the measuring instrument (please order separately).

The vane probe is equipped with a telescope, which can be extended to a maximum length of 1.0 m. The immersion depth is easy to read, even if visibility is poor, thanks to the high-contrast scaling.

The clearly structured measurement menu for volume flow enables the measuring instrument to be operated intuitively. The volume flow is precisely calculated thanks to convenient input of the size and geometry of the duct cross-section. Timed and multi-point mean calculation, average volume flow, current reading and min./max. values are displayed in the measuring instrument.

Particularly useful: press the button on the vane probe to operate the measuring instrument. For example, to store individual readings for multi-point mean calculation or to start and stop measurement series for mean calculation over time.

Space-saving: more applications, less equipment

Endlessly versatile: a universal handle can be connected to all probe heads - so you can master more applications using less equipment and save space.

Order the Bluetooth® handle to make it more convenient to carry out your measurement and guarantee less cable clutter in the case. This transmits the readings to the measuring instrument from a distance of up to 20 meters. If the vane needs to be replaced in the distant future, you can change the probe head.

If required, you can also fit the vane probe with the telescope extension (available to order separately). You can therefore attain a total length of 2 meters, making it easy to carry out measurements on large ventilation systems.

Intelligent calibration concept

You will get exceptionally accurate measurement results with the digital probe, because the measuring instrument makes measurement uncertainty a thing of the past. You only need to send the probe in for calibration - so the measuring instrument remains in continuous use.

Areas of application for the vane probe

Ventilation ducts: Use the vane probe to measure air velocity in ventilation ducts with reliability. Benefit from fast calculation of the volume flow: in the “volume flow” measurement menu of the compatible measuring instrument (please order separately), configure the dimensions and geometry of the duct cross-section - the measuring instrument shows you the volume flow straight away.

Temperature - NTC
Measuring range	14° to 158 °F / -10 to +70 °C
Accuracy	±3.2 °F / ±1.8 °C
Resolution	0.1 °F / 0.1 °C
Velocity / Volume flow
Measuring range	118.1 to 9843 fpm / 0.6 to 50 m/s
Accuracy	±(39.4 fpm + 1 % of mv) (118.1 to +7874 fpm) / ±(0.2 m/s + 1 % of mv) (0.6 to +40 m/s) ±(39.4 fpm + 2 % of mv) (7893.7 to 9843 fpm) / ±(0.2 m/s + 2 % of mv) (40.1 to 50 m/s)
Resolution	19.7 fpm / 0.1 m/s
General technical data
Storage temperature	14° to 158 °F / -10 to +70 °C
Dimensions	31.1 x 2.0 x 1.6 in.
Operating temperature	14° to 158 °F / -10 to +70 °C
Cable length	4.593 ft. / 1.4 m
Length telescope	39.37 in. / 1,000 mm
Probe head diameter	0.63 in. / 16 mm
Diameter telescope	0.63 in. / 16 mm
Weight	15.2 oz. / 430 g

Test Equipment General Attributes
Product Height	6.00 IN
Product Length	36.00 IN
Product Width	6.00 IN
Shipping Weight	2.10 LBS
HTS/Schedule B Number	90268020000
ECCN Number	EAR99
Country of Origin	Germany
Shipping Height	6.00 IN
Shipping Length	36.00 IN
Shipping Width	6.00 IN

Start typing your question...

Answers (1) - Asked by Anonymous

I have this question too (0)

This probe is offered in three formats. It can be purchased by itself, or with a wired or Bluetooth handle. Vane probe (Ø .63", 16mm) with temperature sensor, 0 - 9842.5 fpm •0635 9570 •Probe head only - does not include handle. HANDLE IS NECESSARY TO OPERATE •9" length •0635 9571 •Probe head with Bluetooth handle •22.5 - 39.4" length •0635 9572 •Probe head with fixed cable handle •22.5 - 39.4" length
