Teledyne LeCroy T3AFG80 - Two Channel Arbitrary Waveform Generator, 80 MHz

Name: Teledyne LeCroy T3AFG80 - Two Channel Arbitrary Waveform Generator, 80 MHz
Brand: Teledyne LeCroy
SKU: LeCroyT3AFG80
Price: 1465.00 USD
Availability: InStock

0 reviews | Catalog: T3AFG80 | Model: Teledyne LeCroy T3AFG80

Teledyne Test Tools T3AFG80 - Two Channel Arbitrary Waveform Generator, 80 MHz

Compare

80 MHz, 1.2 GS/s, 8 Mpts, 2 Channel, 20 Vpp Function/Arbitrary Waveform Generator

Wide range of modulation types
Built in arbitrary waveforms
User defined waveforms
1 and 2 channel models available
Available in several bandwidths
Sweep output carrier can be Sine, Square, Triangle and Arbitrary waveforms
Burst output under internal or external signal control
Waveforms types include DC

View Product Details

Your Price: $1,465.00

In Stock:

Request a Demo

View Payment Options

Request Quote

Recommended for you

Teledyne LeCroy T3AFG80 Accessories

Choose a Category

Function Generator / Frequency Counter Kits

for the Teledyne LeCroy T3AFG80

Cal Test CT4037 Advanced Function Generator Accessory Kit

Catalog: CT4037

(11)

In Stock!

Add to Cart

Teledyne LeCroy T3AFG80 - Two Channel Arbitrary Waveform Generator, 80 MHz

Sine: 1 μHz ~ 80 MHz/li>
Maximum sampling rate: 1.2 GS/s
Built in arbitrary waveforms
Burst output under internal or external signal control

Teledyne LeCroy T3AFG range of generators are a series of single and dual-channel function/arbitrary waveform generators with specifications of up to 120 MHz maximum bandwidth, 1.2GSa/s maximum sampling rate, and 14 or 16-bit vertical resolution. The proprietary TrueArb and EasyPulse techniques used on the higher bandwidth models help to solve the weaknesses inherent in traditional DDS generators when generating arbitrary, square, and pulse waveform. With the advantages above the T3AFG generators can provide users with a variety of high fidelity and low jitter signals, which can meet the growing requirements of complex and extensive applications.

Tools for Improved Debugging

Deep Memory - up to 8 Mpts/Ch on 40 MHz to 120 MHz models. 16 kpts on 5 MHz and 10 MHz models.
Wide Range of Modulation Types - AM, DSB-AM, FM, PM, FSK, ASK, PWM, Sweep, Burst, and PSK on 2 Ch models.
High Resolution - 14 Bit on 5 MHz and 10 MHz models, 16 bit on 40 MHz to 120 MHz models.
Bandwidth Models up to 120 MHz
Built-In Arbitrary Waveforms
User-Defined Waveforms
Generate complex arbitrary waveforms.
Quickly set up modulated waveforms.
Generate waveforms with low noise and spurious signal content.
Wide choice of bandwidths.
Load and replay built-in Arbitrary Waveforms.
Store and recall user-defined waveforms.

General Specifications
Frequency Specification
Model	T3AFG5	T3AFG10	T3AFG40	T3AFG80	T3AFG120
Waveform	Sine, Square, Ramp, Pulse, Noise, Arbitrary
Sine	1 μHz ~ 5 MHz	1 μHz ~ 10 MHz	1 μHz ~ 40 MHz	1 μHz ~ 80 MHz	1 μHz ~ 120 MHz
Square	1 μHz ~ 5 MHz	1 μHz ~ 10 MHz	1 μHz ~ 25 MHz
Pulse	500 μHz ~ 5 MHz		1 μHz ~ 25 MHz
Ramp/Triangular	1 μHz ~ 300 kHz		1 μHz ~ 1 MHz
Gaussian white noise	> 5 MHz (–3 dB)	> 10 MHz (–3 dB)	> 40 MHz (–3 dB)	> 80 MHz (–3 dB)	120 MHz (–3 dB)
Arbitrary	1 μHz ~ 5 MHz		1 μHz ~ 20 MHz
Resolution	1 μHz
Accuracy	Within 90 days ±50 ppm within 1 year ±100 ppm		10-year aging ± 3.5 ppm at 25 Degrees C
Sine Wave
Harmonic Distortion	DC ~ 1 MHz ≤ 60 dBc 1 MHz ~ 10 MHz ≤ 55 dBc		DC ~ 10 MHz ≤ 65 dBc 10 MHz ~ 20 MHz ≤ 60 dBc 20 MHz ~ 40 MHz ≤ 55 dBc 40 MHz ~ 60 MHz ≤ 50 dBc 60 MHz ~ 80 MHz ≤ 45 dBc 80 MHz ~ 100 MHz ≤ 40 dBc 100 MHz ~ 120 MHz ≤ 38 dBc
Total harmonic waveform distortion	DC ~ 20 kHz, 1 Vpp < 0.2 %		0.075 %, 0 dBm, 10 Hz ~ 20 kHz
Spurious signal(non-harmonic)	DC ~ 1 MHz ≤ 70 dBc 1 MHz ~ 10 MHz ≤ 60 dBc		DC < 50 MHz ≤ 70 dBc > 50 MHz ≤ 65 dBc
Square Wave
Rise/fall time	< 24 ns (10 % ~ 90 %)		9 ns (10 % ~ 90 %)
Overshoot	< 5 % (typical, 1 kHz, 1 Vpp)		3 % (typical, 100 kHz, 1 Vpp, 50 Ohm Load)
Duty Cycle	20 % ~ 80 %		0.001 % ~ 99.999 % Limited By Frequency
Jitter	500 ps + 0.001 % of period		150 ps, 1 Vpp, 50 Ohm Load
Pulse
Pulse width	16 ns, Min. 1 ns resolution		16.3 ns, Min
Rise/Fall time (10% ~ 90%, typical)	20 ns ~ 1.6 ks		8.4 ns ~ 22.4 s
Duty Cycle	0.1 % Resolution		0.001 % ~ 99.999 %, 0.001 % Resolution, Limited by Pulse Width
Overshoot	< 5 %		3 % (typical,100 kHz,1 Vpp, 50 Ohm Load)
Jitter(pk-pk)	500 ps + 0.001 % of period		150 ps, 1 Vpp, 50 Ohm Load
Ramp/Triangle Wave
Linearity	< 0.1 % of Vpp (typical, 1 kHz, 1 Vpp, 100 % symmetric)		≤ 1 % of Vpp (typical, 1 kHz, 1 Vpp, 100 % symmetric)
Symmetry	0 % ~ 100 %		0 % ~ 100 %
Harmonic Output
Order	N/A		10 Maximum
Type	N/A		Even, Odd, All
Arbitrary Wave
Waveform length	16 k points		8 M points
Vertical resolution	14 bits		16 bits
Sample rate	125 MSa/s		75 MSa/s TrueArb Mode, 300 MSa/s DDS Mode
Min. Rise/Fall time	8 ns (typical)		8 ns (typical)
Jitter(pk-pk)	8 ns (typical)		150 ps, 1 Vpp, 50 Ohm Load, TrueArb Mode
Storage in non-volatile RAM memory (10 in total)	10 waveforms		10 waveforms

Generators / Counters/Function Generator Template
Channels	2
Frequency Maximum	80 MHz
Test Equipment General Attributes
Product Height	8.00 IN
Product Length	14.00 IN
Product Width	13.00 IN
Shipping Weight	13.00 LBS
Country of Origin	China
Shipping Height	8.00 IN
Shipping Length	14.00 IN
Shipping Width	13.00 IN
