Tektronix P5100A - High Voltage Single Ended Probes (500 MHz)

Safe high voltage probe solutions for ground-referenced voltage testing. It is critical to safely and accurately capture real-time signal information from "elevated" or "floating" voltage systems. Our portfolio of high voltage probes provides the safety you need for single-ended, differential or isolated measurements.

Applications

In many applications, it is important to be able to isolate the measurement from earth ground and also to isolate the common voltage between channels. The P5100A, coupled with the TPS2000 and THS3000Series digital storage oscilloscopes, delivers both the isolation for the measurement from earth ground and full isolation between the channels. The P5100A is the recommended probe for measuring ripple on high-voltage DC supplies. The P5122 probe should not be used on the TPS2000 Series oscilloscopes for AC-coupled measurements on signals with greater than300 V DC offset.
