| Channels |
| Number of channels |
2 |
| Built-in waveforms |
| Built-in waveforms |
Sine, Square, Pulse, Ramp, Noise, and 45 frequently used arbitrary waveforms |
| Sine wave |
| Range |
1 μHz to 60 MHz |
| Sine wave in burst mode |
2 mHz to 30 MHz |
| Effective maximum frequency out |
60 MHz |
| Amplitude flatness (1 V p-p ) |
|
<10 MHz
|
±0.5 dB
|
|
≥10 MHz to 25 MHz
|
±0.7 dB
|
| Harmonic distortion |
< -60 dBc |
| Total harmonic distortion |
< 0.2% (10 Hz to 20 kHz, 1 V p-p ) |
| Spurious |
< -45 dBc |
| Phase noise |
1 MHz: < -110 dBc/Hz at 10 kHz offset, 1 V p-p (typical) |
| Residual clock noise |
-57 dBm (typical) |
| Square wave |
| Range |
1 μHz to 30 MHz |
| Rise/fall time |
< 10 ns |
| Jitter (rms) |
< 500 ps |
| Overshoot |
<5% |
| Ramp wave |
| Range |
1 μHz to 2 MHz |
| Linearity |
≤ 0.1% of peak output at 10% - 90% of amplitude range, at 1 kHz, 1 V p-p , 50% symmetry (typical) |
| Symmetry |
0.0% to 100.0% |
| Pulse wave |
| Range |
1 μHz to 30 MHz |
| Pulse width range |
17 ns to 999 ks |
| Pulse width resolution |
1 ps or 4 digits |
| Pulse duty |
<1 MHz, 0.1% to 99.9% (limitations of pulse duty width apply)
1 MHz to 30 MHz, 50% fixed |
| Edge transition time |
< 10 ns, fixed |
| Overshoot |
< 5% (typical) |
| Jitter |
<500 ps |
| Noise |
| Noise bandwidth (-3 dB) |
50 MHz |
| Noise type |
White Gausian |
| DC |
| Range |
-5 V to +5 V, 50 Ω load
10 V to + 10 V, open circuit or high Z load |
| Arbitrary waveform |
| Range |
1 μHz to 30 MHz |
| Arbitrary waveform in burst mode |
2 mHz to 30 MHz |
| Effective analog bandwidth (-3 dB) |
60 MHz |
| Non-volatile memory |
64 MByte |
| Memory |
|
Length
|
2 to 1 M-point
|
|
Sampling rate
|
300 MS/s
|
| Vertical resolution |
14 bits |
| Rise and fall time |
< 8 ns |
| Jitter (rms) |
< 6 ns (typical) |
| Frequency |
| Resolution |
1 μHz or 12 digits |
| Internal reference stability |
±1 ppm at 0 - 40 °C |
| Internal reference aging |
±1 ppm per year |
| Amplitude |
| Range |
2 mV p-p to 20 V p-p , open circuit or high Z load |
| Accuracy |
±(1% of setting +1 mV p-p ), (1 kHz sine waveform, 0 V offset) |
| Resolution |
1 mV p-p , 1 mV rms or 4 digits |
| Units |
V p-p , V rms |
| Output impedance |
50 Ω (typical) |
| Local impedance setting |
Selectable: 50 Ω, 1 Ω to 10.000 kΩ, High Z (adjusts displayed amplitude according to selected load impedance) |
| Isolation |
No floating ground, signal ground connected to chassis ground |
| Signal output protection |
Short-circuit tolerance, main output automatically disabled when over current |
| DC offset |
| Range |
±(5 V pk – Amplitude pp /2), 50 Ω load
±(10 V pk – Amplitude pp /2), open circuit or high Z load |
| Accuracy |
±(1% of |setting| + 1 mV + 0.5% of amplitude (V p-p )) |
| Resolution |
1 mV or 4 digits |
| Modulation |
| Modulation, sweeping, and burst modes are only available in channel 1. |
| Amplitude modulation |
|
Carrier waveforms
|
Sine, square, ramp, arbitrary, except DC and noise
|
|
Source
|
Internal / external
|
|
Internal modulating
waveforms
|
Sine, square, ramp, noise, arbitrary
|
|
Internal AM frequency
|
2 mHz to 20 kHz
|
|
Depth
|
0.0% to 100.0%
|
| Frequency modulation |
|
Carrier waveforms
|
Sine, square, ramp, arbitrary, except DC and noise
|
|
Source
|
Internal / external
|
|
Internal modulating
waveforms
|
Sine, square, ramp, noise, arbitrary
|
|
Internal modulating frequency
|
2 mHz to 20 kHz
|
|
Frequency deviation
|
2 mHz to 30 MHz
|
| Phase modulation |
|
Carrier waveforms
|
Sine, square, ramp, arbitrary, except DC and noise
|
|
Source
|
Internal / external
|
|
Internal modulating
waveforms
|
Sine, square, ramp, noise, arbitrary
|
|
Internal PM frequency
|
2 mHz to 20 kHz
|
|
Phase Deviation
|
0° to 180°
|
| Frequency shift keying |
|
Carrier waveforms
|
Sine, square, ramp, arbitrary, except DC and noise
|
|
Source
|
Internal / external
|
|
Internal modulating
waveforms
|
50% duty cycle square
|
|
FSK rate
|
2 mHz to 100 kHz
|
| Sweeping |
| Modulation, sweeping, and burst modes are only available in channel 1. |
| Carrier waveforms |
Sine, square, ramp |
| Minimum start-stop frequency |
1 μHz |
| Maximum start-stop frequency |
Sine: 60 MHz
Square: 30 MHz
Ramp: 2 MHz |
| Type |
Linear, logarithmic |
| Direction |
Up / down |
| Sweep time |
1 ms to 500 s ± 0.1% |
| Trigger sources |
Internal, external, or manual |
| Burst |
| Modulation, sweeping, and burst modes are only available in channel 1. |
| Waveforms |
Sine, square, ramp, pulse, arbitrary except DC and noise |
| Types |
Count (1 to 50,000 cycles), infinite, gated |
| Start phase |
-360° to +360° |
| Trigger sources |
Internal, external, or manual |
| Internal trigger interval |
(40 ns or (cycles x period) to 500 s) ± 1% |
| Gate source |
External trigger |
| Frequency counter |
| Function |
Frequency, period, positive pulse width, duty cycle |
| Frequency range |
100 mHz to 200 MHz |
| Frequency resolution |
6 digits |
| Coupling mode |
AC, DC |
Voltage Range and Sensitivity, DC
coupled (non-modulation signal) |
|
100 mHz to 100 MHz
|
250 mV p-p to 5 V p-p (AC + DC)
|
|
100 MHz to 200 MHz
|
450 mV p-p to 3 V p-p (AC + DC)
|
Voltage range and sensitivity, AC
coupled (non-modulation signal) |
|
1 Hz to 100 MHz
|
250 mV p-p to 5 V p-p
|
|
100 MHz to 200 MHz
|
450 mV p-p to 4 V p-p
|
| Frequency counter |
Pulse width and duty cycle
measure |
1 Hz to 10 MHz |
| Input impedance |
1 M Ω in parallel with 100 pF |
High frequency noise restraint
(HFR) |
On / Off (HFR frequency = 500 kHz) |
| Sensitivity |
Low, middle, or high |
| Trigger level range |
-2.5 V to +2.5 V |
| Auxiliary inputs and outputs |
| External modulation input |
|
Input frequency range
|
DC to 20 kHz
|
|
Input voltage range
|
All except FSK: ±1 V full scale, FSK: 3.3 V logic level
|
|
Input impedance
|
12 kΩ (typical)
|
| External trigger input |
|
Level
|
TTL-compatible
|
|
Slope
|
Rising or falling (selectable)
|
|
Pulse Width
|
>100 ns
|
|
External reference clock input
|
(Shared with Frequency Counter Input)
|
|
Impedance
|
400 Ω, AC coupled
|
|
Requested Input voltage
swing
|
100 mV p-p to 5 V p-p
|
|
Locking range
|
10 MHz ±9 kHz
|
| External reference clock output |
|
Frequency
|
10 MHz
|
|
Impedance
|
50 Ω, DC coupled
|
|
Amplitude
|
1.6 V p-p into 50 Ω load
|
| Communication interface |
|
USB
|
Host and device, USB TMC compliance
|
| Display |
| Display type |
3.95-inch |
| Display resolution |
480 by 320 |
| Display colors |
65,536 |
| Menu and online help languages |
| Menu and online help languages |
English and Simplified Chinese |
| Power source |
| Supply |
220-240 VAC, 100-120 VAC, 50/60 Hz, CAT Ⅱ |
| Consumption |
Less than 28 W |
| Fuse |
110 V: 250 V, F1AL
220 V: 250 V, F0.5AL |
| Warm-up time |
30 minutes (typical) |
| Physical characteristics |
| Dimensions (W, H, D) |
235 × 110 × 295 mm (9.2 × 4.33 × 11.61 in) |
| Weight |
|
Net
|
3.4 kg (7.4 lbs)
|
|
Shipping
|
4.7 kg (10.3 lbs)
|
| EMC environment and safety |
| Temperature |
|
Working
|
0 ℃ to 40 ℃ (32 °F to 104 °F)
|
|
Storage
|
-20 ℃ to 60 ℃ (-4 °F to 144 °F)
|
Relative humidity (non-
condensing) |
Operating: ≤ 80%, +0 °C to +40 °C (+32 °F to +104 °F)
Non-operating: 5% to 90%, < +40 °C (+104 °F)
Non-operating: 5% to 80%, ≥ +40 °C (+104 °F) to ≤ +60 °C (+140 °F) |
| Altitude |
Operating: up to 3,000 m (9842 ft.)
Non-operating: up to 12,000 m (39,368 ft) |
| Cooling method |
Fan cooling |
| EMC compliance |
|
European Union
|
EN 61326-1
|
|
Australia/NZ
|
CISPR 11, Class A
|
| Safety compliance |
| UL 61010-1 |
| CAN/CSA-C22.2 No. 61010-1 |
| EN 61010-1 |
| IEC 61010-1 |
