Tabor LS6081D-DST - 6GHz RF Signal Generator Desktop Module

• Model LS6081D-DST
• 6 GHz RF signal generator desktop module
• Fast switching speed
• Multi instrument synchronization capability
• Remotely programmable via MATLAB, Python, LabVIEW and other software programming environments

The all-new Lucid series offers the most advanced features and industry-leading performance in the most compact form factor. The series features 3, 6, and 12GHz single-channel versions, all sharing the very same industry-leading highlighted features, in a compact, small footprint module. Featuring fast switching speed, superior signal integrity, and purity, all the necessary modulated signals for analog communication systems, with built-in SPI and micro-USB interface, the Lucid series is designed to meet today’s most demanding specifications, needed to form the R&D benches to the production lines.

Signal Integrity and Purity

One of the most important requirements in today’s testing and measurement applications is high signal quality. With a typical SSB phase noise of -145dBc at 100MHz, and -132dBc at 1GHz, at 10kHz carrier offset, Tabor’s all-new Lucid series platform delivers one of the best quality signals available on the market today, answering the ever-rowing demand for clear and precise signals.

Fast Switching

In today’s world, time is a crucial factor, whether in design, on the production floor or inside ATE systems. Tabor’s all-new Lucid series ensures maximum measurements at minimum time, setting the industry’s highest throughput standard.

Modulation Schemes

Signal bursts and chirps have become a common need in the daily life of any aerospace or defense applications. With Tabor’s all-new Lucid series, any modulation is possible, no matter if it’s AM, FM, PM, or Sweep.

Multiple Ways to Control the Unit

Tabor’s Lucid series comes with its own dedicated software to control the instrument functions, modes, and features via a graphical user interface (GUI) as well as a complete set of drivers, allowing you to write your application in various environments including Labview, Python, CVI, C++, VB, and MATLab. You may also link the supplied dll to other Windows-based API’s or use low-level SCPI commands to program the instrument.
