| Basic DC accuracy |
0.05% |
| Compare |
Compares stored value with measured value for matching components |
| Data Hold |
Enables the reading on the display to be frozed. The two hold system hold the previous reading when a new one is recieved |
| Relative |
Display a measured value as a percentage of a stored value. Useful for component testing. |
| Record |
Record Minimum, Maximum, and average reading. |
| Auto Range |
Automatically selects the best range for measurement |
| Continuity & Buzzer |
Check for opens and shorts |
| RS232 |
Optically isolated software optional |
| Safety |
Designed to meet cULus 3111 and IEC1010 |
| LCD |
Large 50,000 count display |
| Triple Display |
Shows more than one reading simultaneously |
| Bar Graph |
51 Segments Analog Bar Graph to catch fast AC fluctuations |
| Back Light |
Allows viewing in any light condition |
| True RMS |
Needed to accurately measure ninsinusoidal AC voltage and current waveforms found on controls and cicuits |
| Test Leads |
Silicone rubber 1,000 CAT III, 600V CAT IV, 10A |
| Auto Power Off |
DMM will automatically power down after approximately 15 minutes of inactivity to extend battery life. Disable Auto Power Off: Hold down the REC button and turn the meter on |
| Diode Test |
Displays approximate forward bias voltage |
| GENERAL SPECIFICATIONS |
| Weight |
530g |
| Operating Temp |
0°C to 45°C (-32°F to 113°F) |
| Storage Temp |
-20°C to 60°C (-40°F to 140°F) |
| Relative Humidity |
0% to 80%: (0°C to 35°C/32°F to 95°F) |
| 0% to 70% |
(45°C to 55°C/95°F to 131°F) |
| Temp Coefficient |
0.1x (Specified Accuracy) per °C for temperature <18°C to >28°C |
| Power Supply |
9 Volt Alkaline Battery |
| OPTIONAL ACCESSORIES |
| A100 |
Carrying Case |
| A191 |
RS232 cable & software for optically isolated IR port |
| A251 |
AC Clamp-On Accessory for DMMs 0-400 Amps |
| A254 |
Low Current AC/DC Adapter for DMMs 10 Amp range, 0.001 resolution 60 Amp range, 0.01 resolution |
| A256 |
AC/DC Clamp-On Accessory for DMMs 0.1 A resolution |
| A296 |
AC/DC Clamp-On Accessory for DMMs 0-1,000 Amps |
| A301 |
Temperature Adapter with GK11M and battery, 0.1°C or °F resolution |
| A620 |
500psi Pressure/Vacuum Adapter for DMMs |
