| Basic DC accuracy | 0.05% |
| Compare | Compares stored value with measured value for matching components |
| Data Hold | Enables the reading on the display to be frozed. The two hold system hold the previous reading when a new one is recieved |
| Relative | Display a measured value as a percentage of a stored value. Useful for component testing. |
| Record | Record Minimum, Maximum, and average reading. |
| Auto Range | Automatically selects the best range for measurement |
| Continuity & Buzzer | Check for opens and shorts |
| RS232 | Optically isolated software optional |
| Safety | Designed to meet cULus 3111 and IEC1010 |
| LCD | Large 50,000 count display |
| Triple Display | Shows more than one reading simultaneously |
| Bar Graph | 51 Segments Analog Bar Graph to catch fast AC fluctuations |
| Back Light | Allows viewing in any light condition |
| True RMS | Needed to accurately measure ninsinusoidal AC voltage and current waveforms found on controls and cicuits |
| Test Leads | Silicone rubber 1,000 CAT III, 600V CAT IV, 10A |
| Auto Power Off | DMM will automatically power down after approximately 15 minutes of inactivity to extend battery life. Disable Auto Power Off: Hold down the REC button and turn the meter on |
| Diode Test | Displays approximate forward bias voltage |
| GENERAL SPECIFICATIONS |
| Weight | 530g |
| Operating Temp | 0?C to 45?C (-32?F to 113?F) |
| Storage Temp | -20?C to 60?C (-40?F to 140?F) |
| Relative Humidity | 0% to 80%: (0?C to 35?C/32?F to 95?F) |
| 0% to 70% | (45?C to 55?C/95?F to 131?F) |
| Temp Coefficient | 0.1x (Specified Accuracy) per ?C for temperature <18?C to >28?C |
| Power Supply | 9 Volt Alkaline Battery |
| OPTIONAL ACCESSORIES | 9 Volt Alkaline Battery |
| OPTIONAL ACCESSORIES |
| A100 | Carrying Case |
| A191 | RS232 cable & software for optically isolated IR port |
| A251 | AC Clamp-On Accessory for DMMs 0-400 Amps |
| A254 | Low Current AC/DC Adapter for DMMs 10 Amp range, 0.001 resolution 60 Amp range, 0.01 resolution |
| A256 | AC/DC Clamp-On Accessory for DMMs 0.1 A resolution |
| A296 | AC/DC Clamp-On Accessory for DMMs 0-1,000 Amps |
| A301 | Temperature Adapter with GK11M and battery, 0.1?C or ?F resolution |
| A620 | 500psi Pressure/Vacuum Adapter for DMMs |
| Specification | 190
(resolution) | 192
(resolution) | 194
(resolution) |
| AC Volts | Max. reading
Frequency
Best resolution | 750
(45Hz to 20kHz)
(0.0001V) | 750
(45Hz to 20kHz)
(0.0001V) | 750
(45Hz to 20kHz)
(0.0001V) |
| DC Millivolts | Max. reading
Best resolution | 500
(0.0001mV) | 500
(0.0001mV) | 500
(0.0001mV) |
| DC Volts | Max. reading
Best resolution | 1,000
(0.0001V) | 1,000
(0.0001V) | 1,000
(0.0001V) |
| DC Microamps | Max. reading
Best resolution | 5,000
(0.01uA) | 5,000
(0.01uA) | 5,000
(0.01uA) |
| DC Milliamps | Max. reading
Best resolution | 500
(0.001mA) | 500
(0.001mA) | 500
(0.001mA) |
| DC Amps | Max. reading
Best resolution | 10
(0.0001A) | 10
(0.0001A) | 10
(0.0001A) |
| AC Microamps | Max. reading
Best resolution | 5,000
(0.01uA) | 5,000
(0.01uA) | 5,000
(0.01uA) |
| AC Milliamps | Max. reading
Best resolution | 500
(0.001mA) | 500
(0.001mA) | 500
(0.001mA) |
| AC Amps | Max. reading
Best resolution | 10
(0.0001A) | 10
(0.0001A) | 10
(0.0001A) |
| Ohms | Max. reading
Best resolution | 500
(0.01 ohm) | 500
(0.01 ohm) | 500
(0.01 ohm) |
| Kohms | Max. reading
Best resolution | 500
(0.0001 Kohm) | 500
(0.0001 Kohm) | 500
(0.0001 Kohm) |
| Mohms | Max. reading
Best resolution | 50
(0.0001 Mohm) | 50
(0.0001 Mohm) | 50
(0.0001 Mohm) |
| Frequency Hz | Max. reading
Best resolution | 500
(0.001Hz) | 500
(0.001Hz) | 500
(0.001Hz) |
| Frequency kHz | Max. reading
Best resolution | 500
(0.0001kHz) | 500
(0.0001kHz) | 500
(0.0001kHz) |
| Inductance mH | Max. reading
Best resolution | no | 100
(0.01) | no |
Capacitance
Nano Farads | Max. reading
Best resolution | no | 500
(0.01) | no |
Capacitance
Micro Farads | Max. reading
Best resolution | 20,000
(0.001) | 100
(0.001) | 20,000
(0.001) |
| Safety | | CAT II 1,000V
CAT III 600V | CAT II 1,000V
CAT III 600V | CAT III 1,000V
CAT IV 600V |
| Fuse | | 600V 500mA
600V 10A | 600V 500mA
600V 10A | 1000V 440mA
1000V 11A |
